Copper aluminum Round hollow steel tube pipe straightener machine
The steel tube straightening machine is used for restoring the bending and distorted tubes, after restoring, the tube will be no indentation and diameter reducing. The machien is the ideal equipment for building construction companies and steel tube rental enterprise , scafflod construction unit.
The steel pipe straghtening machine is consist of straightening system , removing rust machine, and painting box. It can be used for only straightening, also for straightening and rust removing and painting at the same time. Mechnical rollers straightening , stable and durable .
Features of the steel tube straightener machine
1. Adopts mechnical driving, reasobale structure, easy operation.
2. Multip function, with functions of straightening, rust removing, and painting.
Can meet various needs, time saving, labour saving and high efficicency.
3. the mechnical speed can be control, the steel tube diamter range is 48-50mm.
stable running, low noise and easy move.
4. the machine can straighten 6 meters per minute. Straightening, derusting and brushing paint will be done at the same time.
functions of the steel tube straightener machine
1. Straighten the steel pipe/steel pope
2. Removing the rust on the surface of the steel pipe
3. Remove sand ,soil , dirty on the surface of the steel pipe
4. Paint the steel pipe and steel tube
technical data of the steel tube straightener machine
Model |
YW-48A ( eight rollers) |
YW-48B ( six rollers) |
YW-48C |
Straightening diameter range |
45-51mm |
45-51mm |
45-51mm |
Motor Power (KW) |
3kw+3kw+3kw |
3kw+3kw+3kw |
4kw+4kw+4kw |
voltage |
380v |
380v |
380v |
Working speed |
12m/min |
12m/min |
18m/min |
Weight |
950kg |
900kg |
1050kg |
Size L*W*H |
2600x800x1200mm |
2750x800x1200mm |
2900x800x1100mm |
Straightening angle |
60 degrees |
60 degrees |
60 degrees |
Function |
Remove rust, dirty, straighten, paint. |
Remove rust, dirty, straighten, paint. |
Remove rust, dirty, straighten, paint. |
Zhengzhou yingwang machinery co., ltd has 15 years of experience in washing powder mixer production and sales.
We adopt advanced production technology, produce high quality machine.and always uphold the quality first, customer-oriented principle, to win the big market of domestics and abroad. Our products have been exported to Europe, America, Asia and African and other regions. OEM service is also available. we insist on "First Quality, First Trust, and First Serice"as our business philosophy, forcuses on international and domestic markets, strives for excellence. we are sincerelly expecting to cooperate with you and win-win, warmly welcome to visit our company, let's create bright future together.
If you are interested in steel tube straightener machine,welcome contact with me anytime.
