China Elegant Mini Wheel Loader DY840 Small Garden Loader With Hedge Trimmer
china elegant mini wheel loader DY840 small garden loader with hedge trimmer :
Our company was established in 2001, and since then we have been focus on all kinds of loaders development, good innovation ability enable us to keep developing and stand out from other similar products. We have been awarded with 4 patents till now, variable products can meet customers different requirements.
1.Compact design
2.Hydrostatic four wheel drive
3.Telescopic boom
4.Self levering.
5.Differential lock.
6.Boom floating
7.European standard quick coupling plate
8.Front articulated structure makes the turning radius much smaller.
1.Unique telescopic design, widely increase its usage, and also this new design bring something fresh to the loader business, big advantage for re-sell also.
2.Quick coupling system and compatible attachments enable the loaders can do many different kind of work. you can find all what you need here in our factory.
3.Many options enable you to make the ideal machine in your mind, and also offer much choices about the cost.
4.Another big advantage compared with other normal loaders, ours can be equipped with rear hydraulic output & 3 point hitch, which makes it can turn into a tractor. So you spent the money for a loader and get both loader and tractor.
1.The engine is original Perkins or Kubota;
2.The pump, joystick, are Italian Hansa brand;
3.The valves are Italian Hydro Control brand;
4.The seals are from German B+Sbrand;
5.European standard quick coupling system.
Standard specifications as below. But if you have any special requirement, please feel free to brin up, our company has more than 10 years experience with all kinds of loaders, and is the first one who start manufacturer compact telescopic loaders, our engineers has rich experience with customers' special requirements, we'll try our best to satisfy you.
Model | DY840 |
Dimension (LxWxH) | 2600 X1240 X 2100mm |
Max. reach(boom extended) | 3000mm |
Max. reach(boom retracted) | 2480mm |
Bucket capacity | 450L |
Rated loading capacity | 850kg |
Tipping load | 1300kg |
Min. turning radius | 2065mm |
Turning angle | 450 |
Speed | 0-12 km/h |
Weight | 1600 kg |
Standard tire | 26X12-12 |
Tire pressure | 2.8 bar |
Oil tank capacity | 40L |
Pressure | 190bar |
Working oil flow | 33.5L/minx2 |
Tracking oil flow | 78L/min |
Oil model(mineral oil) | L-HL46 |
Engine brand | Perkins 404D-15/ Kubota V1505-E3B |
Engine type
| 4 cylinder, water cooling |
Rated power/speed | 24.5 Kw/2800 r/min |
Fuel tank capacity | 23L |
Battery | 60Ah, 12V |
