small wheel loader Taian DY620 small articulated wheel loader with telescopic boom
- 500 Unit / Units per Month
- Qingdao China
- T/T
Product Details
Condition: | New | Brand Name: | TAIAN | Model Number: | DY620 |
Place of Origin: | Shandong, China | Type: | Mini Loader | Moving Type: | Wheel Loader |
Dimension(Long * Breadth * High): | 2195x980x2150mm | Rated Load: | 500kg | Certification: | CE, EPA, FOPS ROPS |
Warranty: | one year or 1000 working hours whichever comes first | After-sales Service Provided: | Overseas third-party support available |
Product Description
small wheel loader Taian DY620 small articulated wheel loader with telescopic boom
DY620 small wheel loader
1.ROPS Cabin or canopy can protect the driver in any case if there’s a tilt danger.
2.Top rotating warning light give an eye-catching signals to people around.
3.Warning signals for maintenance and operating protect the machine from over-use.
4.Reversing beeper and lights, traffic lights, rear and front working lights well protects people around and also the operator.
5.Cylinder protection can prevent any possible damage caused by the boom falling down.
DY620 small wheel loader
1.All models have separately four hydraulic wheel motor, they are real four wheel drive hydrostatic dive.
2.All machines adopts world famous Kubota/Perkins which guarantees the quality and meanwhile more powerful.
3.All the actions of the machine can be achieved by only joystick/levels, buttons and switches, reasonable arrangements of all the controls makes the operating biggest comfortable.
4.Thanks to the quick coupling system, you can change into different attachments in just one minute, which is very simple and convenient.
5.We always take customers’ any possible needs into consideration, there’s cigar-lights on each machine.
6.We equipped window hook for the closed cabin so that the window can be opened a bit and offer better ventilation
Model | DY620 |
Dimension (LxWxH) | 2195 mm*980 mm*2150 mm |
Max. reach(boom extended) | 2750mm |
Max. reach(boom retracted) | 2480mm |
Bucket capacity | 300L |
Rated loading capacity | 500kg-800kg |
Min. turning radius | 1980mm |
Turning angle | 400 |
Speed | 10 km/h |
Weight | 1100 kg |
Standard tire | 23X8.5-12 |
Tire pressure | 2.8 bar |
Oil tank capacity | 35L |
Pressure | 190bar |
Working oil flow | 33L/min |
Tracking oil flow | 50L/min |
Oil model(mineral oil) | L-HL46 |
Fuel tank capacity | 18L |
Battery capacity | 55Ah |
Voltage | 12v |
Engine brand | Chinese Changchai 3M78 |
Engine type | 3 cylinders, water cooling |
Rated power/speed | 16kw / 2800r/min |
OPTIONS OF ENGINE | |
Engine brand | Yanmar 3TNV382A |
Engine type | 3 cylinders, water cooling |
Rated power/speed | 22.2KW / 3000r/min |
1.For the new machine, within determined limits, the manufacture guarantees for a period of 12 months after bought or 1000 working hours(whichever comes first).
2.The warranty includes repairation or replace the parts for free which were proved to be defective in origin by the technical department of the manufacture.
3.The repairation or replacement for the parts should not exceed the warranty period.
4.The warranty is valid on the condition of all the terms listed in the contract was observed.
If you are interested in this machine and need a quotation, Please contact with: Steven.
