ASTM A179 Seamless Cold Drawn Low Carbon Steel Heat Exchanger

FOB Price

US$ 500 - 800 / Ton

2 Tons(Min. Order)

Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Thickness	1, 15
Section Shape	Round	Outer Diameter	6.0 - 168 mm
Place of Origin	Hubei, China	Secondary Or Not	Non-secondary
Application	Boiler Pipe	Technique	Cold Drawn
Certification	Other	Surface Treatment	Galvanized
Alloy Or Not	Non-alloy

Product Description

Applications:

Because of ASTM A179 grade’s temperature withstanding capabilities, it is applied to steel pipe of tubular heat exchanger, condensers and similar heat transfer equipment. Our ASTM A179 seamless tubes are used in sugar mills & distilleries, pumps and petrochemicals, cement and construction industries and steel plants.

Features:

1)Dimensional accuracy.

2)High strength

3)Durable

4)Corrosion resistance

5)Fine finish

Detailed Images

Chemical Composition(%):

C	Mn	P	S
0.06–0.18	0.27–0.63	0.035 max	0.035 max

Mechanical Properties:

Tensile Strength(Mpa)	Yield Strength(Mpa)	Elongation(%)	Hardness(HRB)
325 Min	180 Min	35 Min	72 max

Specifications:

Standard	ASTM A179
O.D.	6.0mm-168.0mm
W.T.	1mm-15mm
Length	25000mm max
Surface treatment	Oil-dip, varnish, Passivation, phosphating, Shot Blasting
Inspection and Tests Performed	Chemical Composition inspection, Mechanical Properties Test(Tensile Strength, Yield Strength, Elongation, Flaring, Flattening, Hardness, Impact Test), Surface and Dimension Test, No-destructive Test, Hydrostatic Test.
Delivery Condition	Annealed, Normalized, Normalized and Tempered
PackingInspection and Tests Performed	Chemical Composition inspection, Mechanical Properties Test(Tensile Strength, Yield Strength, Elongation, Flaring, Flattening, Hardness, Impact Test), Surface and Dimension Test, No-destructive Test, Hydrostatic Test

Notes:

1)Mill test certificates will be issued according to EN10204.3

2)All tubes shall be supplied as per applicable ASTM Specification.

3)The tubes Shall be Seamless and the testing shall be as per A 450 / A450M.

Product Pictures
