| Product name | Stainless steel seamless pipe/tube |
| Procuction Standards |
ASTM A312, ASTM A358, ASTM A813,ASTM A814 etc. |
| Grade | 201,304,304H,316,316L,316Ti,321,321H,310,904L. |
| Outer Diameter | 10~630mm |
| Wall Thickness | 1.5~50mm |
| Length | 5.8m, 6m, 11.8m, 12m, Random length, or as required |
| Delivery conditions | N-(normalizing); A-(annealing); T-(tempering); Q-(quenching); N+T; Q+T.etc |
| Processing | Galvanizing; cutting; making thread outside the pipe; Machining. |
| NPS Designator | Outside Diameter in. | Schedule 10S in. | Schedule 40S in. | Schedule 80S in. | Schedule 160 in. | Schedule XX in. |
| 1/4 | 0.540 | 0.065 | 0.088 | 0.119 | ||
| 3/8 | 0.675 | 0.065 | 0.091 | 0.126 | ||
| 1/2 | 0.840 | 0.083 | 0.109 | 0.147 | .188 | .294 |
| 3/4 | 1.050 | 0.083 | 0.113 | 0.154 | .218 | .308 |
| 1.0 | 1.315 | 0.109 | 0.133 | 0.179 | .250 | .358 |
| 1 1/4 | 1.660 | 0.109 | 0.140 | 0.191 | .250 | .382 |
| 1 1/2 | 1.900 | 0.109 | 0.145 | 0.200 | .281 | .400 |
| 2 | 2.375 | 0.109 | 0.154 | 0.218 | .343 | .436 |
| 2 1/2 | 2.875 | 0.120 | 0.203 | 0.276 | .375 | .552 |
| 3 | 3.500 | 0.120 | 0.216 | 0.300 | .438 | .600 |
| 3 1/2 | 4.000 | 0.120 | 0.226 | 0.318 | .636 | |
| 4 | 4.500 | 0.120 | 0.237 | 0.337 | .534 | .674 |
| 5 | 5.563 | 0.134 | 0.258 | 0.375 | .625 | .750 |
| 6 | 6.625 | 0.134 | 0.280 | 0.432 | .719 | .864 |
| 8 | 8.625 | 0.148 | 0.322 | 0.500 | .906 | .875 |
| 10 | 10.750 | 0.165 | 0.365 | 0.500 | 1.125 | |
| 12 | 12.750 | 0.180 | 0.375 | 0.500 | 1.312 | |
| 14 | 14.000 | 0.188 | 0.375 | 0.500 | 1.406 | |
| 16 | 16.000 | 0.188 | 0.375 | 0.500 | 1.594 |
| Element | Min % | Max % |
| Iron (Fe) | Balance | Balance |
| Manganese (Mn) | 2.00 | 2.00 |
| Chromium (Cr) | 18.0 | 20.0 |
| Silicon (Si) | 0.75 | 0.75 |
| Nickel (Ni) | 8.00 | 12.0 |
| Sulfur (S) | 0.03 | 0.03 |
| Carbon (C) | 0.03 | 0.03 |
| Nitrogen (N) | 0.10 | 0.10 |
| Phosphorus (P) | 0.00 | 0.04 |
304LV Stainless Steel Mechanical properties
Room Temperature (Annealed):
| Properties | Metric | English |
| Tensile Strength | 483 MPa | 70,000 PSI |
| Yield Strength | 173 MPa | 25,000 PSI |
| Elongation (at break) | 40% | 40% |
| Hardness (Rockwell B) | 92 HRB Max. | 92 HRB Max. |
304LV Stainless Steel Physical properties
| Metric | English |
|
Density |
7.29 g/cm³ | 0.285 lbs/in³ |
Modulus of elasticity |
193 GPa | 28.0 Mpsi |
Electrical resistivity |
720 µohms*mm |
28.4 µohms*in |
Thermal conductivity |
15.65 W/(m*°C) |
9.05 BTU*in/(hr*ft²*°F) |
Coefficient of linear thermal expansion |
16.92 µm/(m*°C) |
9.4 µin/(in*°F) |
| Grade | UNS | DIN | EN | AMS | ASTM | JIS | |
| 304LV | UNS S30400 | - | ASTM A 276 ASTM A 313 ASTM A 666 |
||||
304LV Stainless Steel Applications
Medical Implants
Surgical Instruments
Catheters
Guide Wire
Springs and Needles
Orthodontic Wire
Zhongzheng Stainless Steel Co., Ltd. was established in 2018 with aregistered capital of 20 million yuan. lt is a manufacturing company thatintegrates the production of special materials, manufacturing andprocessing, sales, and technology development. The company covers anarea of 2,000 square meters and has 200 employees. it has built worldclass stainless steel seamless pipe (hot piercing, cold drawing, cold rollingproduction lines, precision steel pipe production lines, and large, mediumand small-sized welded pipe production lines. The company has beencommitted to providing high performance, high precision, hightemperature-resistant, high pressure-resistant, and corrosion-resistantsolutions and technical services for industrial equipment pipeline systems.The company specializes in producing a series of steel pipes, pipe fittingsflanges, etc., such as high-temperature (nickel-based) alloys, austeniticduplex steel, urea grade stainless steel, super stainless steel, etc. Thecompany is equipped with an annual production capacity of 5,000 tons ofstainless steel seamless pipe production line, 7,000 tons of welded pipeproduction line, and 500 tons of pipe fittings production line, etc. lt canoroduce stainless steel seamless pipes with diameters ranging from Φ6 toΦ762 and wall thicknesses ranging from 0.5 to 70 mm, stainless steelwelded pipes with diameters ranging from Φ15 to Φ2200 and wallthicknesses ranging from 0.5 to 80 mm, pipe fittings, and various stainlesssteel ingots, round steel, rough pipes, etc., according to customerrequirements and in accordance with standards such as GB, ASTM, etc.
After-sale capability:
Flexible payment via T/T, L/C, etc
Fast delivery and standard export packaging
Familiar with after-sales service technology, able to provide customers with quality after-sales service
Our company will be for each shipment will have the strict quality control, at the same time we also apply for the international reputation of the third party inspection and quarantine company quality control, such as SGS, BV, ITS, TUV, Intertek, CCIC, DEKRA, UL, LRQA and inspection report issued by a third party
