EN 10216-1 Non-alloy Steel Tubes

FOB Price

US$ 850 - 1,350 / Metric Ton

2 Metric Tons(Min. Order)

Port shanghai
Payment TermsT/T Money Gram

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

You May Like

Product Details

Thickness	1.6, 60
Section Shape	Round		Outer Diameter	10.2 - 720 mm
Place of Origin	Hubei, China		Secondary Or Not	Non-secondary
Application	Boiler Pipe		Certification	Other
Surface Treatment	Other		Alloy Or Not	Non-alloy

Product Description

Product Description

EN 10216-1 Non-alloy Steel Tubes

Application:

For producing storage tanks of heat-resistant steels used in boiler-making, tool-making;

For constructing pressure reservoirs and high pressure are simultaneously used to have summarized load and special conditions.

Detailed Images

Chemical Composition:

Grade	Steel No.	C	Si	Mn	P	S	Cr	Mo
P195TR1	1.0107	0.13 max	0.35 max	0.70 max	0.025 max	0.020 max	0.30 max	0.08 max
P195TR2	1.0108	0.13 max	0.35 max	0.70 max	0.025 max	0.020 max	0.30 max	0.08 max
P235TR1	1.0254	0.16 max	0.35 max	1.20 max	0.025 max	0.020 max	0.30 max	0.08 max
P235TR2	1.0255	0.16 max	0.35 max	1.20 max	0.025 max	0.020 max	0.30 max	0.08 max
P265TR1	1.0258	0.20 max	0.35 max	1.40 max	0.025 max	0.020 max	0.30 max	0.08 max
P265TR2	1.0259	0.20 max	0.35 max	1.40 max	0.025 max	0.020 max	0.30 max	0.08 max

Grade	Steel No.	Ni	Al	Cu	Nb	Ti	V
P195TR1	1.0107	0.30 max	/	0.30 max	0.01 max	0.04 max	0.02 max
P195TR2	1.0108	0.30 max	0.02 min	0.30 max	0.01 max	0.04 max	0.02 max
P235TR1	1.0254	0.30 max	/	0.30 max	0.01 max	0.04 max	0.02 max
P235TR2	1.0255	0.30 max	0.02 min	0.30 max	0.01 max	0.04 max	0.02 max
P265TR1	1.0258	0.30 max	/	0.30 max	0.01 max	0.04 max	0.02 max
P265TR2	1.0259	0.30 max	0.02 min	0.30 max	0.01 max	0.04 max	0.02 max

Mechanical Properties:

Steel No.	Wall Thickness 16mm max Yield Strength R2 (Mpa)	Wall Thickness 16mm-40mm Yield Strength R2 (Mpa)	Wall Thickness 40mm-60mm Yield Strength R2 (Mpa)	Tensile Strength Rm (Mpa)	Elongation(%)(L)	Elongation(%)(T)
P195TR1	1.0107	195 min	185 min	175 min	320-440	27 min
P195TR2	1.0108	195 min	185 min	175 min	320-440	27 min
P235TR1	1.0254	235 min	225 min	215 min	360-500	25 min
P235TR2	1.0255	235 min	225 min	215 min	360-500	25 min
P265TR1	1.0258	265 min	255 min	245 min	410-570	21 min
P265TR2	1.0259	265 min	255 min	245 min	410-570	21 min

Steel No.	Elongation(%)(T)	Izod Impact (J) at 0°C(L)	Izod Impact (J) at -10°C(L)	Izod Impact (J) at 0°C(T)
P195TR1	25 min	/	/	/
P195TR2	25 min	40 min	28 min	27 min
P235TR1	23 min	/	/	/
P235TR2	23 min	40 min	28 min	27 min
P265TR1	19 min	/	/	/
P265TR2	19 min	40 min	28 min	27 min

Specification:

Standard	BS EN 10216-1
Grade	P195TR1, P195TR2, P235TR1, P235TR2, P265TR1, P265TR2
O.D	10.2mm-720mm
W.T	1.6mm-60mm
Packing	Standard export packing or following customer's demand.
Delievery	By sea container
