Flexographic Printing Machine (6 Colors)

Flexographic Printing Machine (6 Colors) thumbnail-1
Flexographic Printing Machine (6 Colors) photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Other, Flexographic
Place of Origin:
Zhejiang, China
Contact Supplier Request Quote Chat Now
Ruian Guotai Plastic Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Other, Flexographic
Place of Origin Zhejiang, China
Brand Name Guo Tai
Model Number YT-6600/6800/61000/61200
Usage Other, film non-wevon etc

Specifications

This Double-color Flexographic Printing Macine is a Easy operation, flexible starting, accurate color register.

Product IDYT
SortPrinting machine series
NameYT Series Double-color Flexography Printing Machine



YT Series Double-color Flexography Printing Machine
Application: Introduce sensitization resin as flexible printing plate, suitable for printing
such packing materials as polyethylene, polypropylene bag, cellophane and roll paper,
etc. It is a kind of ideal printing equipment for producing paper packing bag for food,
supermarket handbag, vest bag and clothes bag, etc.

Performance and Features
1. Easy operation, flexible starting, accurate color register.
2. The meter counter can set printing quantity according to the requirements. Stop the machine automatically at the quantity or when the material is cut off.
3. Pneumatic printing cylinder lift and lower, it will stir the printing ink automatically after lifting.
4. The printing ink is spread by the anilox cylinder with even ink color.
5. Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.
6.360°continuous and adjustable longitudinal register device.
7. The frequency control of motor speed adapts to different printing speeds.
8. There are Jogging/Stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.

Main Technical   Variables:

Type YT-6600 YT-6800 YT-61000
Max. Web Width 600mm 800mm 1000mm
Max. Effective Printing Width 560mm 760mm 960mm
Range of Repeat Printing Length 191914mm 191914mm 191914mm
Max. Diameter of Roll Material 450mm 450mm 450mm
Printing Speed 550m/min 550m/min 550m/min
Plate Thickness(Both side adhesive tape included) 2.38mm 2.38mm 2.38mm
Total Power 8Kw 10Kw 12Kw
Overall Dimension 2300×1860×2145mm 2300×2060×2145mm 2300×2260×2145mm
