QTM type high speed paper roll to roll five colours flexo printing machine
Email:manager at
Skype:qtmachine
Mobile:0086-13306877870
Contact person:Miss kiki
Specifications
QTM type 4 Colours High Speed kraft paper printing machine
It features novel appearance, stable and accurate color and big winding torque.
The main features:
1. Take it easy, accurate color, long life
2. The use of motors, variable frequency speed control, saving electricity, running small fluctuations
3. Off printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink
4. The use of special diagonal-tooth gear, print size is accurate,
5. There are two sets of heating devices, including central heating and constant temperature control system for packet control
6. Low-roller special steel processing, and special process, and plating thickness of 0.1mm protective layer of hard chromium
7 Alloy roll with hard oxidation, treating by dynamic balance, static balanced
8 With a cold wind bellows, and can effectively prevent produce with ink adhesion after printing
9. The Print produce are clear and good arrangement quality
10. Bearing: NSK, Japan brand, Germany ASNU aluminum alloy roll
Main Technical Parameter:
Printing width Item |
600mm |
800mm |
1000mm |
1200mm |
1400mm |
1600mm |
1800mm |
2000mm |
||
Printing material |
Single adhesive paper,Double adhesive paper,Copper plate paper,Kraft paper :50-180g/m²; Single filter membrance paper,Double filter membrance paper : 80-300g/m² |
|||||||||
Printing color |
4 special color |
|||||||||
Material feeding width |
700mm |
900mm |
1100mm |
1300mm |
1500mm |
1700mm |
1900mm |
2100mm |
||
Printing length |
7.5"-40" (90mm-1016mm) ; 7.5"-50" (90mm-1270mm) |
|||||||||
Printing plate lifting system |
Pneumatic/Hydraulic press control |
|||||||||
Mechanical speed |
100m/min |
|||||||||
Printing speed |
80m/min |
|||||||||
Anilox cylinder |
80DK-170DK(Germany)/180LPI-800LPI |
|||||||||
Register precision |
Longitude:±0.1mm Transverse: ±0.1mm |
|||||||||
Rewinder/Unwinder DIA |
ø 1000mm /ø 1200mm /ø 1500mm |
|||||||||
Master motor |
5.5W |
7.5KW |
11W |
15KW |
||||||
Rewinder motor |
5.5KW |
7.5KW |
||||||||
Unwinder motor |
5.5KW |
7.5KW |
||||||||
Electrical header |
26KW |
32KW |
38KW |
45KW |
||||||
Blower of header |
0.75KW |
1.1 KW W |
1.5 K W |
2.2 K W |
||||||
Blower of nature wind |
0.75 KW |
1.1 KW |
1.5 KW |
2.2 KW |
||||||
Inking motor |
370W |
750W |
||||||||
Master frequency converter |
5.5KW |
7.5KW |
11KW |
15 KW |
||||||
Master power |
45KW |
54KW |
68KW |
82KW |
||||||
Weight |
8100Kg |
g8760Kg |
9300 Kg |
9750 Kg |
10120Kg |
10500Kg |
11000Kg |
11700Kg |
||
