Metal Pleated Filter Cartridge
Introduction:
Stainless steel pleated filter cartridge is composed of stainless steel fiber sintered felt,stainless steel metal wire mesh, is a multilayer filtering element after pleating and rolling, 3-5katers generally. Stainless steel fiber sintered felt is a multiporous and deep filtering materials after high-temperature sinering of stainless steel fibers to be formmed into trapezoidal aperture from thick to thin.
Filter material: import metal fiber sintered felt, domestic metal fiber sintered felt, 304 Microgroove web, 304 Square hole webs.
Applications: the field of chemical fiber, petroleum chemical and all the related chemical industry.
It is of pleated structure, able to bear huge amount of dirt, can be cleaned repeatedly, firm and not easy to be deformed, high-temperature resistance.
The below is our main specification, you can choose your needs from it.
Main Specification:
φ |
L |
M2 |
M1 |
Pattern |
Filter Fineness |
Operating Pressure |
Operating Temperature |
35 |
217 |
M20×1.5 |
M5 |
Welded |
3~100 |
Max 30Mpa |
≤310 |
35 |
425 |
M20×1.5/2 |
M5 |
Welded |
|||
35 |
485 |
M20×1.5/2 |
M5 |
Welded/ Assembled |
|||
50 |
515 |
M27×2 |
M6 |
Welded/ Assembled |
|||
50 |
515 |
M27×3 |
M6 |
Welded/ Assembled |
|||
58 |
515 |
M33×2 |
M8 |
Welded/ Assembled |
|||
58 |
515 |
M36×3 |
M8 |
Welded/ Assembled |
|||
60 |
1215 |
M36×3 |
M8 |
Welded/ Assembled |
