PTFE Pleated Filter Cartridge
US$ 20 - 300
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
yofull
After-sales Service Provided:
Engineers available to service machinery overseas
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Surface Polished Titanium Sintered Filter Cartridge/Chemical Filter CandlesUS$ 50 - 700MOQ: 100 Pieces -
Titanium Sintered Filter Cartridge/Filter CandlesUS$ 100 - 1,000MOQ: 10 Pieces
-
Metal Pleated Filter Cartridge,Filter Candle,Stainless Steel FilterNegotiableMOQ: 10 Pieces
-
SS Filter ElementUS$ 20 - 300MOQ: 100 Pieces
-
Metal Pleated Filter CartridgeUS$ 20 - 300MOQ: 10 Sets
Place of Origin
Zhejiang, China
Brand Name
yofull
After-sales Service Provided
Engineers available to service machinery overseas
PTFE Pleated Filter Cartridge
- It is divided into hydrophilic and hydrophobic
- Consists of PTFE film, PP accessories or soluable PTFE accessories(PTA).
- With extremely good chemical stability.almost resists to all organic or inorganic chemical corrosives.
- With excellent heat resistance.
Techniacal parameters list
| Precision | 0.01(Gas) | 0.2(Liquid) | 0.45(Liquid) |
| Bubbling point(bar) | 2.2 | 2.2 | 1.2 |
| Length | 5″10″20″30″40″ | Work temperature | <90℃ |
| Diameter | 2.75″ | Work temperature | < 150℃ |
| Filtering materials | PTFE | Max temperature resistance | < 121℃ |
| Support materials | PP/soluble PTFE | Maximum temperature | < 180℃ |
| Case materials | PP/soluble PTFE | Max inlet pressure | 5.5bar(25℃) |
| Filtering area | >0.6m²/10″ | Recommended changeover period | < 1 year or < 50times steam sterilization |
| Sterillization temperature | 121℃,30min(50 times) | Max pressure difference | 4.0bar(25℃) |
