Cnc Router 4d 4 Axis 6/8/12heads Rotary Servo

Name: Cnc Router 4d 4 Axis 6/8/12heads Rotary Servo
Brand: tian jiao
Availability: InStock

FOB Price

US$ 14,500 - 17,000 / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsT/T Money Gram Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	CNC or Not	CNC
Place of Origin	Shandong, China	Brand Name	tian jiao
Model Number	TJ120-25	Voltage	AC380V
Power(W)	2.2KW	Dimension(LWH)	310022002100mm
Weight	2000kg	Certification	CE
Warranty	12 Months	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

cnc router 4d 4 axis 6/8/12heads rotary servo

Product Description

Pictures:

configuration:

2.2KW air cooling spindle

Thick Steel structure

Hiwin square orbit,

ballscrew, imported bearings

Taiwan servo motor and driver

Taiwan inverter

Aluminum profile table

DSP A18 4axis control system

Software: JD paint software

19 cutters

features:

1)high-speed 8 head equipment is mainly to solve low efficiency of tranditional wood processing industry, 8 heads can work at the same time, working efficiency is 8 times than single head.

2) mainly suitable industry: woodworking furniture carving ,wood crafts,wood carve patterns or designs, woodworking carving handicrafts.

parameters:

Performance Parameters
Model	TJ12025	TJ3020
Working Area	1200*2000mm	3000*2000mm
Max Moving Speed	25m/min	25m/min
Max Engraving Speed	15-20m/min	15-20m/min
Reposition Accuracy	<0.03mm	<0.03mm
Operating system	DSP Controller A18
Spindle	China made 2.2kw air Cooling
table	Aluminum profile table
Transmission way	TBI ballscrew
Driving system	Taiwan servo motor and driver
spindle	2.2kw air cooling spindle
Inverter	Taiwan inverter
Spindle Speed	0-18000rpm
Tool Diameter	3.175, 6
Proper Materials	Plastic, Wood, MDF, PVC,acrylic, bamboo , etc.
Application	This machine is widely used in woodworking industry.. Wood table legs making, 3D relief carving and cutting, statute making, etc.

package:

service

Before sale

1.Patient introduce and professional suggest buying selection

2.Real time report production situation

3.Take pictures and make videoes with your done machine

4. Strict test and debugg machine quality before shipping

After sale

24 hours on line service and phone on

2 years gurantee term

During gurantee term, repair or change damaged parts for free

Exceed gurantee term, offer at cost price
