Home > Products > Concrete Mixing Plant > Concrete Plant Factory HZS50, 1m3 Concrete Mixer Machine for Concrete Plant

Concrete Plant Factory HZS50, 1m3 Concrete Mixer Machine for Concrete Plant

FOB Price

US$ 1 - 40,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Power Type	Electric
Place of Origin	Henan, China	Brand Name	YUJIE
Model Number	HZS50	Power(W)	110kw
Dimension(LWH)	33.8m14.8m10.8m	Weight	40T
Certification	CE ISO TUV SASO	Warranty	12 Months
After-sales Service Provided	Engineers available to service machinery overseas

concrete plant factory HZS50, 1m concrete mixer machine for concrete plant

Product Description

Main parts:

1.Concrete trasit mixer: capacity 3m3 to 16m3 ;

2.Aggregate batching machine: PLD1600.

3.cement silo: 50T;

4.water, cement, fly ash and additive weighing scales;

5.screw conveyor;

ntrol system.

2. Specification

Model	HZS50
Rated Productivity	50m3/h
concrete transit mixer	3m3 to 16m3 (it depends on the customer)
Max. Aggregate Diameter	80mm
Capacity of Aggregate Bin	3×13m3
Aggregate Conveying Mode	Lift Hopper
Aggregate Weighing Precision	3000Kg ±2%
Cement Weighing Precision	600Kg ±1%
Fly Ash Weighing Precision	400Kg ±1%
Water Weighing Precision	400Kg ±1%
Additive Weighing Precision	50Kg ±1%
General Power	85Kw
Total Weight	40T
Outline dimension (LWH)	33.8m×14.8m×10.8m
Discharging Height	3.8 m
Control Mode	Semi-automatic batching, manual operation
Powder Silos (for customers choice)	The capacity and number of silos as well as the configuration of silo accessories vary with customers’ demands.
Screw Conveyors (for customers choice)	Usually, φ273mm screw conveyors are used.

More photos

Mixing system

Batching system

Cement silo and screw conveyor

Control system
