hzs120 concrete batching plant,new technoligy concrete mixing plant 120m3/h

Name: hzs120 concrete batching plant,new technoligy concrete mixing plant 120m3/h
Brand: YUJIE
Availability: InStock

FOB Price

USD $1 - $160,000 / Set

1 Set(Min.Order)

Supply Ability 50 Set / Sets per Month
Port Qingdao
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Power Type	Electric
Place of Origin	Henan, China	Brand Name	YUJIE
Model Number	HZS120	Power(W)	130kw
Dimension(LWH)	44m18m12.7m	Weight	88T
Certification	GBT/19001-2008/ISO9001:2008	Warranty	12 Months
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

hzs120 concrete batching plant,new technoligy concrete mixing plant 120m3/h

Product Description

Brief introduction

HZS120 Ready mixed Concrete BatchingPlant Construction Machinery is designed and developed and based on introducing and digesting both home and abroad’s similar type products *advanced technical* advantages and using experience. Concrete Mixing Machine is widely used for architecture project transportation project, construction of municipal, water conservancy, airport construction, port construction Metallurgy Mining and construction building site of all series.

Characters of hzs120 concrete mixing plant

1. Special design for Construction Project;

2. Easy operate;

3. Convenient structures for disassembly;

4. Super property and low production cost;

5. Less space demand.

6.full -automatic electric operation with PLC/PC control

7.electrical weighing system

8.twin shaft forced mixing system

Advantages

1. Less funds possession. Yujie brand is famous in China. Maybe we have no Zoomlion's quality, but we have low price than them. Maybe we have no such low price like some small factory, but we have high quality. In a words, HIGH COST PERFORMANCE.

2. Less space occupation. We have good experience on custom design. No matter T type or -- type, all design for space save.

3. Less equipment application. One batcher can storage(big storage bin 12m3), weighting, no need more machine. The lessest equipment, the biggest work.

4. Accurate meaurement of batching machine. Accurate is our advantage, also our aim. You know, accurate means good matching, means high quality concrete. All of our weighing system error ≤ 2%. We promise it.

5. High quality concrete producing. Our plant widely use in China goverment project, such as undergrand metro, high speed way, dam etc.

6.Heat preservation system and cooling system are available. We have good experience on it because we have exported to Russia, Myanmar, Uzbekistan such cool or hot weather countries. Our heat system or cooling system get good feedback and work very well.

Main parameters

Model	HZS120
Rated Productivity	120m3/h
Main Mixer	JS2000
Max. Aggregate Diameter	80mm
Capacity of Aggregate Bin	4X16m3
Aggregate Conveying Mode	Flat Belt Conveyor
Aggregate Weighing Precision	4X 4500Kg ±2%
Cement Weighing Precision	1500Kg ±1%
Fly Ash Weighing Precision	1500Kg ±1%
Water Weighing Precision	1000Kg ±1%
Additive Weighing Precision	100Kg ±1%
General Power	200Kw
Total Weight	88T
Outline dimension (LWH)	44m×18m×12.7m
Discharging Height	4.1m
Powder Silos (for customers choice)	Tvary with customers’ demands.
Screw Conveyors (for customers choice)	Usually, φ219mm or φ273mm screw conveyors are used.

More photos

Mixing system

Batching system

Packaging & Shipping

Our Services
