CT312 Tig/mma/cut Welding Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
zzwelder
Model Number:
CT-312
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CT312 3 in 1 Plasma Cutter Has Three Function TIG,MMA and CUTNegotiableMOQ: 1 Set -
CT416 Inverter Welder Has Three Function TIG,MMA and CUTNegotiableMOQ: 1 Set
-
WSM-180 Tig Welding Machine(with Impulse)NegotiableMOQ: 1 Set
-
WSM-300 Inverter Welder With PluseNegotiableMOQ: 1 Set
-
Inverter WelderNegotiableMOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
zzwelder
Model Number
CT-312
Input Voltage
220V
Dimensions
371*155*295
Usage
It can cut many kinds of metals.
Certification
ISO9001/CCC
Specifications
1.tig/mma/cut welding machine has new high-efficiency,cost-effective.2.For tig/mma/cut in triple-purpose.
♣Functions and features:
tig/mma/cut welding machine has new, highly-efficient and economical . Applicable for argon arc welding, electric welding and cutting.More convenient operation, creating new values for you
| Item | TIG | MMA | CUT | TIG | MMA |
CUT |
|||
| Input supply voltage frequency(V.HZ) | AC220±15%,50/60 | AC220±10%,50/60 | |||||||
| Rated input power capacity(KVA) | 3.5 | 4.8 | |||||||
| Output current range(A) | 10~125 | 10~110 | 10~30 | 10-160 | 10~150 | 20~40 | |||
| Rated input current(A) | 10 | 14.7 | 15.87 | 13.7 | 15.87 | 21.7 | |||
| Rate output voltage(V) | 15 | 25 | 92 | 16 | 27 | 96 | |||
| Duty cycle(%)(25°C) | 60 | 40 | |||||||
| No-load loss(W) | 35 | 40 | |||||||
| Efficiency(%) | 85 | 85 | |||||||
| Power factor(COSφ) | 0.93 | 0.93 | |||||||
| Arcing Way | HF | Contact | Contact | HF | Contact | Contact | |||
| Weight(KG) | 9 | 13 | |||||||
| Overall dimension(mm) | 371×155×295 | 425×205×355 | |||||||
| Insulation class | B | B | |||||||
| protection class | IP21 | 1P21 | |||||||
| Max cutting thickness (mm) | - | - | 8 | - | - | 12 | |||
| Maximum electrode diameter(mm) | - | 2.5 | - | - | 3.2 | - | |||
| Gas flow(L/min) | 2.5 | - | 80 | 2.5 | - | 80 | |||
| Nozzle diameter(mm) | - | - | 1.0 | - | - | 1.2 | |||
| Air pressure(Mpa) | -- | - | 0.4 | - | - | 0.4 | |||
