Arc Welding Cable H01N2-D

Name: Arc Welding Cable H01N2-D
Brand: Elsine
SKU: 121765617
Availability: InStock

US$ 1 - 20 MOQ: 5 Kilometers

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

Elsine

Model Number:

H01N2-D YH YHF

Wenzhou Elsine Electric Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name Elsine

Model Number H01N2-D YH YHF

Insulation Material Rubber

Type Low Voltage

Application Construction

Conductor Material Copper

Jacket Rubber

Specifications

Connection of welding machine, the core should be applied to electric voltage 200V for two times with leaning to ground of 400V

H01N2-D Flexible rubber insulated welding cord

Executive standard: GB5013.6-97,60245 IEC 81,DIN VDE 0282-803, BS638-4

Operating characteristics:

1,The cable has high flexible properties

2,The sheath shall be natural rubber compound or neoprene rubber compound,

so it’s applicable for different working conditions.Also it has the outstanding

electrical properties and the excellent mechanical properties

3,The sheath has flame, fire,oil resistance

4,Max.operating temperature of conductor is 90°c

Conductor: untinned soft annealed stranded copper wires class 5, tinned or untinned stranded copper

Application: For connecting electrical appliances and units where extra flexible cord is required (for example ARC welding units)

Specification:

Nominal cross-section area mm²	Nos.of core/ diameter mm	Nominal thickness of sheath mm	Average Outer diameter mm		Max.resistance of conductor at 20°c Ω/km		reference weight kg/km
Nominal cross-section area mm²	Nos.of core/ diameter mm	Nominal thickness of sheath mm	max.	min.	Copper wire	Tinned copper	reference weight kg/km
10	322/0.20	1.8	7.5	9.7	1.91	1.95	146
16	513/0.20	2.0	9.2	11.5	1.16	1.19	230
25	789/0.20	2.0	10.5	13.0	0.758	0.780	344
35	1121/0.20	2.0	11.5	14.5	0.536	0.552	437
50	1596/0.20	2.2	13.5	17.0	0.379	0.390	594
70	2214/0.20	2.4	15.0	19.5	0.268	0.276	793
95	2997/0.20	2.6	17.0	22.0	0.198	0.204	1106
120	1702/0.3	2.8	19.0	24.0	0.161	0.164	1377
150	2135/0.3	3.0	21.0	27.0	0.129	0.132	1709
185	1443/0.4	3.2	22.0	29.0	0.106	0.108	2075
