Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > H07RN-F Flexible Rubber Cable (5G2.5)

H07RN-F Flexible Rubber Cable (5G2.5)

Name: H07RN-F Flexible Rubber Cable (5G2.5)
Brand: Elsine
SKU: 121765633
Availability: InStock

H07RN-F Flexible Rubber Cable (5G2.5) thumbnail-1

H07RN-F Flexible Rubber Cable (5G2.5) photo-1

Negotiable MOQ: 10 Kilometers (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

Elsine

Model Number:

H07RN-F H05RN-F

Contact Supplier Request Quote Chat Now

Wenzhou Elsine Electric Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name Elsine

Model Number H07RN-F H05RN-F

Insulation Material Other, EPDM EPR

Type Low Voltage

Application Industrial

Conductor Material Copper

Jacket Rubber

Specifications

connect electrical appliances under medium mechanical duties in dry,damp&wet room as well as outdoors.Also fixed installation

Application: For connection of electrical appliances under medium mechanical duties in dry,damp and wet rooms as well as outdoors.Also for fixed installation on walls or parts of machines.The cable is oil,ozone and UV-resistant

Rated voltage: U0/U:450/750V

Max. admissible operating temperature of the conductor: 90°c

The bending radius of cable:

6×Cable Diameter for cables not exceeding 25 mm²

8×Cable Diameter for cables exceeding 25 mm²

Testing voltage: 2.5 kV

Standard: acc. to 60245 IEC 66 (DIN VDE 0282 part 4),BS7919

Conductor: Cu,fine stranded acc. to DIN VDE 0295 class 5 resp. IEC 60228 class 5, class5

Copper to be BS6360

Insulation: Ethlylene Propylene Rubber (EPR), Type EI 4 to BS 7655

Sheath: PCP Rubber compound CPE (Chlorinated Polyethylene) Type EM2 to BS 7655
(other equivalent Synthetic Rubber)

Core colours: Yellow/Green-blue-brown-black-gray

Sheath colour: Black or with customers require

No. of cores × Nominal cross-section
n × mm²

Thickness of insulation

Thickness of sheath

Average outer diameter mm

Reference weight
kg/km

Min.

Max.

5 × 2.5

0.9

2.0

13.3
