Help CenterDH-A4! Console Rework Station, Dinghua Technology!
Related Products
-
Bga Rework Machine DH-A4US$ 20,000 - 22,000MOQ: 1 Set -
DH-A3,bga Rework Station,sales PromotionNegotiableMOQ: 1 Set
-
DH-A3,bga Rework Station,surface Mount,hakko Welding Equipment,sales PromotionNegotiableMOQ: 1 Set
-
Low Cost Bga Machine Bga Reflow Machine Repair Laptop Bga MachineUS$ 4,100 - 5,000MOQ: 1 Piece
-
HD Touch Screen Professional Mobile Phone Repair Station Reflow Soldering Bga Reballing MachineUS$ 4,100 - 5,000MOQ: 1 Piece
Specifications
1.HD optical alignment2.Three independent heating zones, PLC control
3. K-sensor, close loop control
4. Finetune workbench
Business grade BGA rework station
Specifications:
Power supply |
AC220V±10% 50/60Hz |
Power |
6800W |
Top heater |
Hot air 1200W |
Bottom heater |
Hot air 1200W,Infrared 4200W |
Positioning |
V-groove, PCB support can be adjusted in any direction and with external universal fixture |
Temperature control |
K sensor close loop control, 3 independent heating heater |
Temp accuracy |
±2°C |
PCB size |
Max 500*400 mm Min 22*22 mm |
Workbench fine-tuning |
±15mm forward/backward,±15mm right/left |
Placement Accuracy |
±0.01MM |
Camera magnification |
10x-100x |
BGA chip |
2*2-80*80mm |
Minimum chip spacing |
0.15mm |
External Temperature Sensor |
1-5(optional) |
Machine dimension |
(L*W*H): 750*102*100mm |
Packing dimension |
(L*W*H): 116*85*112cm |
Net weight |
97kg |
BGA rework station A4 Main Features
lHD touch screen interface, PLC control
lHD color optical alignment system, optical zoom up to 30 times. Alignment can move around to enlarge BGA observation range, fine-tuning accuracy can be 0.01mm
lTop heater and nozzle 2 in 1 design, alignment, placement, welding and remove automatic.
Top heater height can be adjust after auto process, user-friendly. Placement height and height of top heater can be set or detect auto.
lThree independent heaters all can set 8 segments heating, cooling and constant temperature, saved temperature profile is unlimited. IR preheat area can be controlled according to PCB size
lK sensor close loop control and automatic temperature compensation system. It combines with temperature module, which enables temperature accuracy to ±2°C
lHot air nozzles, 360 degree rotation, easy to install and replace, customized is available.
lV-groove PCB support for rapid, convenience and accurate positioning that fits for all kinds of PCB board.
lPowerful cross flow fan, cooling the PCB board efficient after heating, to prevent it from deformation.
lSound hint system. There is an alarm before the completion of each desoldering and soldering.
lCE certification, with emergency switch and automatic power-off protection device when emergency happens
Extra large IR working area
