Condition New
Place of Origin Guangdong, China
Brand Name Tamprinter
Model Number TM-120140 Semi-automatic Oblique Arm Screen Printer
Usage Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer, Tube Printer
Automatic Grade Semi-Automatic
Voltage 220V 50HZ
Gross Power 5.5KW
Dimensions(L*W*H) 1.4*2.54*1.78m
Weight 660kg
Certification CE
Warranty 1year
After-sales Service Provided Overseas third-party support available
Product Description

 TM-120140 Automatic Oblique CE Flat Screen Printer





video link:

http://youtu.be/d0zJxbDc-Js

youku Video

ttp:///v_show/id_XNTUxOTc1OTgw.html

1. Technical parameter:



Type

TM-120140

Worktable area (mm)

1400X1600

Max printing area (mm)

1200X1400

Max screen fame size (mm)

1550X1700

Thickness of materials (mm)

20

Printing speed

400~900pcs/h

Air pressure (Mpa)

0.4~0.8

Air consumption (L/pcs)

13

Power

5.5KW

Max worktable height (mm)

880

Dimension (LXWXH)

1.4*2.54*1.78m

Weight

660kg

Rated voltage

220V/50Hz


2. Application:

   This series of flat screen printing machine is widely used in electronics industry (such as PCB, thin-film switch and so on), packaging industry (such as cigarette case, wine box, gift box and so on), paper board industry (such as trademark, calendar, oil painting, computer keyboard, new year picture, transfer print paper, adhesive sticker, credit card, plate board and so on).

3. Features:

(1). High precision line and synchronous printing transmission adopts motor drive, speed equality and can be adjusted, balanced speed, speed adjustable.

(2). Oblique arm lifting motor, frequency control, the machine runs smoothly.

(3). Blade and back blade pressure regulating device, and can be adjusted to the thickness and size of printing.

(4). Vacuum adsorption fixed printing pieces.

(5). The printing plate has up and down, left and right, before and after tuning device, which makes it  works accurate and convenient on board.

(6). Equipped with a safety device so that the oblique arm is stopped in an upper position having a reliable security.

(7). Electronic control unit centralized control by the microcomputer controller, the whole operation more simple, flexible, and easy maintenance.
















1. Technical Parameter:

Model No.

TMP-6090

TMP-70100

TMP-90120

Size of printing table (mm)

720X1000

800X1100

1000X1300

Max printing area (mm)

600X900

700X1000

900X1200

Max network installation (mm)

900X1200

1000X1300

1200X1500

Min network installation (mm)

450X550

550X650

650X700

Substrate thickness (mm)

0-20  0-50

0-20  0-50

0-20  0-50

Printing speed (pcs/h)

500-1200

500-1200

400-1000

Working pressure(Mpa)

0.3-0.5

0.3-0.5

0.3-0.5

Air consumption(0.6Mpa)(L/pc)

13/pcs

13/pcs

13/pcs

The minimum height of the table(Relative to the ground)mm

820

820

820

Dimensions(LXWXH)mm

1520X1250X1280

1600X1350X1280

1800X1400X1300

weight

410

480

550

voltage

220V 50Hz

220V 50Hz

380V 50Hz

power

2.3

2.3

3.7



 2. Application

   Flat Screen Printer of this series is widely used in the packaging industry (cigarette packaging, wine packaging, gift packaging and other card paper printing) trademark, calendar, oil painting, computer keyboards, paintings, iron-on transfers, credit cards, stickers, printing; also suitable for the printing of the electronics industry.

3. Performance characteristics

(1). Printing machine is driven by motor drive, which is belt drive, sensitive, balanced speed, speed adjustable.

(2). Oblique arm lifting motor, frequency control, the machine runs smoothly.

(3). Blade and back blade pressure regulating device, and can be adjusted to the thickness and size of printing.

(4). Vacuum adsorption fixed printing pieces.

(5). The printing plate has up and down, left and right, before and after tuning device, which makes it  works accurate and convenient on board.

(6). Equipped with a safety device so that the oblique arm is stopped in an upper position having a reliable security.

(7). Electronic control unit centralized control by the microcomputer controller, the whole operation more simple, flexible, and easy maintenance.
