Home > Products > Screen printing machine > TM-MK large size cylinder steel drum screen printer
TM-MK large size cylinder steel drum screen printer
- 30 Set / Sets per Month
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
- TM-300E cheap round bottle screen printer
- TM-700PT High Precision Vacuum Flat Machine Screen Printer
- TAM-6080s cheap flat manual screen printer
- TM-MK large size cylinder screen printer for drum/pail/keg/bucket Quality Choice
- Tam-1224D Economic Manual Glass Screen Printing Machine
- TM-400F Flat and Round Flexo Screen Printer
Product Details
Condition: | New | Place of Origin: | Guangdong, China | Brand Name: | Tamprinter |
Model Number: | TM-MK | Usage: | Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer, Tube Printer, Other, Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer, Tube Printer, bucket printer | Automatic Grade: | Semi-Automatic |
Voltage: | 220V/110V | Gross Power: | 500w | Dimensions(L*W*H): | 2700*1800*1680mm |
Weight: | 650kg | Certification: | ISO 9001:2008 CE Certification | Warranty: | 1 Year |
After-sales Service Provided: | Overseas third-party support available |
Packaging Details
this steel drum screen printer will be packaged by wooden box/iron box/plywood/carton as required
Product Description
TM-MK large size cylinder steel drum screen printer
This steel drum screen printer is one of our best sellers, here are some information of this steel drum printer
Model No. | TM-MK |
Printing diameter | Φ100mm~Φ600mm |
Max printing thickness | 600mm |
Max substrate arc length | 1200mm |
Max printing speed | 500pcs/hr |
Air consumption | 110litre/min(6bar) |
Power | 110/220V 60/50Hz |
Dimension | 2.7*1.8*1.7m |
Weight | 650kg |
barrel screen printing machine Specifications
1. screen printer for large bucket,barrel,bottle,drum printing
2. good quality,long working life
3. high safety,reliability
4. Cylinder screen printers are multifunctional screen printing machine. They are suitable to print on flat, round, oval shaped products.
5. Cylinder screen printers can print one color at one time. Once replacing frame and ink, they can print 2, 3colors
Bucket screen printing machine Function
1. Microprocessor controls, high automation and easy operation.
2. 4-digit auto counter built-in.
3. With the function of cylindrical and conical printing.
4. Automatic ink scraping, ink withdrawing and worktable lifting.
5. Printing stroke and speed is adjustable to meet different needs.
6. Automatic squeegee balance-keeping ensures equal printing pressure.
7. Worktable and screen frame can be adjusted slightly in horizontal and vertical direction.
8. High precision printing and easy adjustment.
Testing Please provide:
1. 110V or 220V power supply.
2. 5-7 bar compress air.
3. Screen Frame 1 pcs.
4. A jig 1pcs.
5. 5-10 pcs product samples.
Company Profile
Tamprinter printing machinery group limited is one of the most professional special printer supplier of Plastic Field in China. We have supplied OEM service for the domestic counterparts since 2003. OEM products have been achieved CE certification.
Due to business expansion, Shenzhen Tamprinter printing machinery limited International trade department have been separated from the parent company in March 2013.
Key products: Pad printer, Screen printer, UV curing machine, Heat transfer machine.
Major market: Globle.
Business scopes:
1. Research, develop, produce and sell: Pad printer, Screen printer, Heat transfer machine, Hot stamping machine, Pre-post printer(UV curing machine, Flame treatment machine ,UV exposure clich machine, Coating emulsion machine, Silk mesh tighten machine, Screen stencil drying oven, Silk screen frame exposure machine, Steel pad plate oven, IR oven, IR drying tunnel conveyer, ) ;
2. Trade and authorize for the patent of the above products, Services about design, testing, maintenance, and technical consulting ;
3. Valet Manufacture: flame treatment gun,screen frame, Screen Stencil,pad, steel plates, film , Drying Racks Trolley and the relative moulds, jigs and parts;
4. Sale by proxy the relative supporting materials: printing ink, Ink Adjustment tool, Rubber pads Materials, Pad Printing Blade, ink cup and ring, Pad holder, ink roller, Screen Silk, Aluminium Screen Frame, Rubber Squeegee, sensitive emulsion, Emulsion Coating tool, Etching powder, Sensor Switch, Tension meter,Spraying gun, Circuit board, Inkwell, Solenoid Valve, hot stamping foil ,High temperature tape,Stamp plate,Silicon rubber roller,Heat transfer paper,High temperature glue, UV lamp ,UV lamps Trigger etc;
5. Our engineer can communicate with clients at anytime in english, design development use UG, Proe, Autocad, Mastercam ;
6. Import and export business of the above items.
