EN-2800 Flexographic Printing Machine
Model: EN-2800
1. Flexographic Printing Machine Performance and characteristics:
1,easy operation flexible starting, accurate color register.
2,the meter counter can set printing quantity according to the requirements. Stop the machine automatic at the set quantity or when the material is out.
3,lift and lower the printing plate cylinder manualy,it will automatically stir the printing ink after lifting.
4,the printing ink is spread by the circled cylinder with even ink color.
5,reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.
6,360degree continuous and adjustable longitudinal register device.
7,the imported frequency control of motor speed adapts to different printing speeds.
8,there are inching/stopping buttons on the plate roller bass and material rolling rack so as to make it easy operate the machine when the plate is installed.
2. Flexographic Printing Machine Main Technical Parameters:
A. Model: EN-2800mm
B. Material : Paper, Plastic Film, Non-woven fabric Aluminum Foil and so on
C. Max. Material Width: 800mm
D. Max. Width of Printing: 760mm
E. Max. Length of Printing: 1000mm
F. Max. Speed of Material Printing 50m/min
G.Thickness of Plate (including the glue) 2.38mm
3. Unwind Unit:
A.Max.Length of Roller: 1500mm
B. Max. Length of Effective Roller: 800mm
C. Dia. of Roller: 76mm
D.Max.Dia. of Unwind: 800mm
E. Type of Unwind: manual friction
4. Traction Unit:
A. Constitution of Traction: Rubber Roller and Chrome plated Roller
B. Traction Zones: 2
5.Printing Unit:
A. Constitution of Printing: Chrome plated Roller, Rubber Roller, Metal Anilox roller, Plate-glued roller
B. Girth of Pressing Roller: 100-350mm
C. Material of Plate: Resin and Rubber
D. Principle of Work: Gears Drive
E.Type of Chromatically: 360 degree circulating
F. Way of Adjusting: manual
G. Plated-glued roller adjusting: pneumatic system
6.Heating and Drying Unit:
A. Type of Heating and drying : blowing first then heating
B. Heating Zones: Heating Tubes 2 colors 4 zones
C. Power of Heating: 2.2kw
D. Assistance of Drying Length 1m
E. Blowers:2 Fans
F .Power of Blowers:2*0.55kw
7.Electrical Parts:
A. Main motors:2.2kw
B. Ink-Transfer Motor: 1kw
C. An Inverter Equips With the Main Motor
8.Wind Unit:
A.Max.Length of Roller: 1500mm
B.Max.Length of Effective Roller: 800mm
C.Dia.of Roller: 76mm
D.Max.Dia of Wind: 600mm
E. Type of Unwind: manual friction
9. Flexographic Printing Machine Picture show
whole machine:
Machine part:
Flexographic Printing Machine shipping:Loading container in factory.
Our after sale service:
Within one year, we will supply spare parts for free and free DHL,and replace the broken part freely within one year.
Our Engineer service:
We will send technician to customer’s factory to install the machine and teach the worker to operate the machine. And the customer should pay all the cost.
If you are interested in our Products,pls contact me freely.
We are willing to provide our best quotation and service to you.
Waitting for your reply.
Thanks
Fiona
Note: Our factory also could specially make machine size for you, any other requirement, pls feel free to contact me , thanks!
Company:Ruian Enoch Plastic Machinery Co.,Ltd
Website: .
Mobile:0086-18968887620
Tel: 0086-577-65111018 Fax: 0086-577-65111028
