Plasic Bag Printing Plant (EN-4600)
Introduce sensitization resin as flexible printing plate, suitable for printing such packing materials as polyethylene, polypropylene bag, cellophane and roll paper, etc. It is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.
1. Easy operation, flexible starting, accurate color register.
2. The meter counter can set printing quantity according to the requirements. Stop the machine automatically at the quantity or when the material is cut off.
3. Pneumatic printing cylinder lift and lower, it will stir the printing ink automatically after lifting.
4. The printing ink is spread by the anilox cylinder with even ink color.
5. Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.
6.360° Continuous and adjustable longitudinal register device.
7. The frequency control of motor speed adapts to different printing speeds.
8. There are Jogging/Stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.
MODEL OF MACHINE |
EN-4600 |
EN-4800 |
EN-41000 |
MAX.WIDTH OF PRINTING |
560mm |
750mm |
950mm |
PRINTING LENGTH |
220-910mm |
220-910mm |
220-910mm |
MAX.WIDTH OF BASE MATERIAL |
φ450mm |
φ450mm |
φ450mm |
PRINTING SPEED |
5-70m/min |
5-70m/min |
5-70m/min |
THICKNESS OF PLATE(INCLUDING TWO-SIDED GLUE PAPER) |
2.38mm |
2.38mm |
2.38mm |
TOTAL POWER |
9.8kw |
10.5kw |
11.2kw |
WEIGHT OF OVERALL |
3500kg |
4000kg |
4500kg |
OVERALL DIMENSIONS(L×W×H) |
4500×1600×2400mm |
4500×1800×2400mm |
4500×2000×2400mm |
OPTIONAL EQUIPMENT |
1) AUTOMATIC CORRECTION MECHIANISM 2) AUTOMATIC TENSION (DOMESTIC IMPORTED 3) PNEUMATIC 4) TENSION SHAFT |
||
Our factory supply various kinds of machines, we will introduce proper machines as your requirements!
Guarantee period and after-sales services:
12 months since installation finish and machine normal working. During this guarantee period, RUIAN ENOCH will provide spare parts without any charge in case of quality discrepancy caused by us. If the malfunctions are caused by your incorrect operations, RUIAN ENOCH will provide spare parts at cost price.
Long-term service:
RUIAN ENOCH will charge the buyer the cost price of spare parts beyond guarantee time and provide long-term technical guide.
Engineer service:
Installation and Adjusting: If required, the seller will dispatch the technician to your country for installation, commissioning, adjusting the machine and training the workers at your plant. After the Machine arrived destination and the customer wants our technician help them running the machine, we will sent our technician to the place of our customer’s factory and training them, but they should pay the charge as bellowed:1: The charge of the VISA 2:The ticket of the air plane from Our city to the Destination place and the Destination place to our city.3:Hotel 4:Pay the salary to the technician 100 USD per day.
