Specifications
1.Take it easy, accurate color, long life4.print produce are clear and good arrangement quality
EN-61000 Six color1000mm Flexography Printing Machine
Model: EN-61000
1. Main Technical Variables:
print material: non woven fabric, roll paper, plastic film and so on
max printing width:1000mm
max printing length: 100-1000mm
printing speed: 10-50m/min
Thickness of plate(Including Two-sides Glue Paper): 2.38mm
Overall Dimensions: 4600*1800*2500mm
Weight of Machine : 3400kg
Feeding material part:
1,roller length: 1100mm
2,effective printing roller length:960mm
3,roller core diameter of 76mm
4,discharge maximum diameter: 1000mm
Traction parts:
1,traction consists of: chrome-plated roller, rubber roller
2,group number: 6 groups
Printing sections:
1,printing consists of:chrome-plated roll, plate roller, anilox roller, rubber roller
2,plate roller circumference: 100-350mm
3,print material: resin plate or rubber plate
4,Transmission: 0 helical gear drive
5,printing chromatography: 360-degree rotation
6,adjustment method: Manual or Automatic
7,rise and fall of plate roller:manual
Drying system:
1, drying method: blow and heating
2, the heating zones: 6 Color: 6 units
3, heating power: 2.2kw
4, auxiliary drying length: 1 meter
5, fans: 2
6, fan power 600mm: 2*0.55kw
Electrical parts:
1, Main Motor: 6-color 1000mm: 3.5kw
2, Ink Motor: 6-Color: 1000mm: 0.75kw
3, Speed using frequency converter control
Rewinding Part:
1, roller length: 11000mm
2, effective roller length: 1000mm
3, roll core diameter: 76mm
4, discharge maximum diameter: 1000mm
5, rewinding method: friction type
The main list of detailed configuration
1, the main motor (frequency conversion motor): 1: 2.2KW (Shanghai)
2, ink motor: one 0.75kw (Shanghai)
3, host converter: 1 set (Hong Kong)
4, fan: 2 * 0.75KW (Shanghai)
5, aluminum roller guide: (Taiwan)
6, Anilox roller: (China)
7, rubber roller: (China)
8, magnetic braker: one (Shanghai)
9,Tension Controller: (Shanghai)
10,low-voltage electrical appliances: (China Chint Group)
11, photoelectric correction: (China)
12, air shaft: 2 (Ryan glare Machinery Factory)
13, the switch: (Schneider)
14, electrical control box: (China)
15, pneumatic components: (China)
2.Picture show
Printing machine shipping:Loading container in factory
Our after sale service:
Within one year, we will supply spare parts for free and free DHL,and replace the broken part freely within one year.
Our Engineer service:
We will send technician to customer’s factory to install the machine and teach the worker to operate the machine. And the customer should pay all the cost.
If you are interested in our Products,pls contact me freely.
We are willing to provide our best quotation and service to you.
Waitting for your reply.
Thanks
Fiona
Note: Our factory also could specially make machine size for you, any other requirement, pls feel free to contact me , thanks!
Company:Ruian Enoch Plastic Machinery Co.,Ltd
Website: .
Mobile:0086-18968887620
Tel: 0086-577-65111018 Fax: 0086-577-65111028
