Metal Alloy Analyzer
Application area
Spectrometer for metal analysis is widely used in material analysis of various industries, such as iron and steel, non-ferrous metal, metallurgy, machinery, chemical equipment, quality inspection system and so on. It is also used in , routine identification and analysis in metallic smelt industry.
1,Manage blast furnace process control by various processes of blast furnace celerity analysis.
2,Identification of product specifications.
3,Material checking and acceptance.
4,Quality inspection.
Major Features
1,The human oriented design, the standardized and modularized manufacture make the apparatus smaller.
2,The core components are all imported, which strengthen the stability and reliability of the apparatus.
3,We adopt the advanced foreign technologies of excitation source and design the excitation source of high energy, high stability by our own to fulfill the needs of ultrahigh content and trace analysis.
4,It adopts overall exit slit using technology which is convenient for choosing passage and regulating.
5,The high voltage of the PHT in the apparatus is controlled directly by computer and regulated by software, which improved efficiency of the passage.
6,In the apparatus, there is an automatic constant temperature system which solve the problem of bad effects to the optics system caused by changing temperature.
7,The multi-language operation software and flexible configuration enable the apparatus more humanistic.
8,This apparatus can analyze various kinds of matrix, such as Fe, Co, Ni, Ti, Cu, Al, Pb, Mg, Zn and Sn.
Software
Common element content range channel table of ferrous metal materials
Element |
Content range% |
Channel |
Element |
Content range% |
Channel |
Fe |
0.002~0.50 |
1 |
Bi |
0.001~0.50 |
1 |
P |
0.001~2.0 |
1 |
La |
0.005~0.50 |
1 |
S |
0.001~0.35 |
1 |
Ce |
0.005~0.50 |
1 |
B |
0.0005~0.20 |
1 |
Si |
0.001~5.0 |
1 |
Sn |
0.002~0.50 |
1 |
Mg |
0.005~1.0 |
1 |
Sb |
0.002~0.50 |
1 |
Mn |
0.001~20.0 |
2 |
As |
0.001~0.30 |
1 |
Al |
0.001~6.0 |
1 |
C |
0.0025~4.0 |
1 |
V |
0.0005~6.0 |
1 |
Mo |
0.001~10.0 |
1 |
Ti |
0.005~3.0 |
1 |
W |
0.01~22.0 |
2 |
Co |
0.002~15.0 |
2 |
Cu |
0.005~2.5 |
1 |
Pb |
0.005~0.50 |
1 |
Ni |
0.001~30.0 |
2 |
Nb |
0.005~3.0 |
1 |
Cr |
0.001~30.0 |
2 |
Zr |
0.005~0.10 |
1 |
Common element content range channel table of non-ferrous metal
Element |
Content range% |
Channel |
Element |
Content range% |
Channel |
P |
0.005~2.0 |
1 |
Sb |
0.005~0.50 |
1 |
Sn |
0.002~10.0 |
2 |
Al |
0.005~10.0 |
1 |
Zn |
0.01~10.0 |
2 |
Cd |
0.0005~0.50 |
1 |
Si |
0.005~20.0 |
2 |
As |
0.001~0.10 |
1 |
Fe |
0.005~10.0 |
2 |
Bi |
0.002~0.50 |
1 |
Cu |
0.005~10.0 |
2 |
Be |
0.002~0.50 |
1 |
Mg |
0.005~10.0 |
2 |
Zr |
0.002~3.0 |
1 |
Mn |
0.002~3.0 |
1 |
La |
0.001~0.50 |
1 |
Ti |
0.005~1.0 |
1 |
Ce |
0.001~0.50 |
1 |
Ni |
0.005~3.0 |
1 |
Pr |
0.001~0.50 |
1 |
Cr |
0.005~3.0 |
1 |
Nd |
0.001~0.50 |
1 |
Pb |
0.005~10.0 |
2 |
Sm |
0.0005~0.50 |
1 |
B |
0.002~0.50 |
1 |
Ga |
0.0005~0.50 |
1 |
V |
0.002~0.50 |
1 |
Sr |
0.002~0.50 |
1 |
