Huawei AP5030DN AP5130DN 3×3MIMO 802.11a/b/g/n/ac 3 x 3 MIMO Fit AP POE 2.4 GHz 5 GHz bands
AP5030DN & AP5130DN Access Points
Huawei AP5030DN and AP5130DN performance-enhanced 802.11ac APs deliver high-capacity, secure WLAN access services for dense, wide-area user environments such as offices, airports, trains, and sports stadiums.
These APs operate in Fat or Fit mode and offer 3 x 3 MIMO technology (three spatial streams) for wireless data rates up to 1.75 Gbit/s, ensuring lightning-fast downloads and uploads plus outstanding video streaming. Multiple authentication and encryption modes work with advanced user access controls to secure the network.
Connect with Huawei 802.11ac APs for demanding Wi-Fi services today and tomorrow.
Features
- Deploy cost-effective AP5030DN and AP5130DN APs and enjoy state-of-the-art wireless performance at the speed of Gigabit Ethernet
- Fast, reliable wireless access services with 1.75 Gbit/s, 3 x 3 MIMO, and link aggregation for maximum throughput; WMM and priority mapping on the air interface and wired interface; legacy 802.11a/b/g/n client support ensures seamless user connections
- Supports multiple authentication and encryption modes, rogue AP detection, WIDS, and WIPS, as well as unified intelligent user access and mobility management when coupled with an AC or NMS
- Integrated antennas provide omnidirectional coverage without coverage holes; available with built-in antennas or flexible external antennas
- Easy to deploy: PoE power supply in compliance with IEEE 802.3af/at simplifies AP installation and supports Plug-and-Play (PnP) in Fit AP mode
Specifications
Specifications |
AP5030DN |
AP5130DN |
Dimensions (H x W x D) |
220 mm x 220 mm x 53 mm |
220 mm x 220 mm x 53 mm |
Power Input |
12V DC ± 10% PoE: –48V DC (in compliance with IEEE 802.3af/at) |
12V DC ± 10% PoE: –48V DC (in compliance with IEEE 802.3af/at) |
Maximum Power Consumption |
13W |
13W |
Operating Temperature |
–10℃ to +50℃ |
–10℃ to +50℃ |
Antenna Type/Antenna Gain |
Built-in antenna/2.4 GHz: 4 dBi, 5 GHz: 5 dBi |
Removable RP-SMA antenna/2.4 GHz: 3.5 dBi, 5 GHz: 4 dBi |
Maximum Number of Concurrent Users |
≤ 256 |
≤ 256 |
Maximum Transmit Power |
25 dBm (combined power) |
25 dBm (combined power) |
MIMO: Spatial Streams |
3 x 3:3 |
3 x 3:3 |
Radio Protocol |
802.11a/b/g/n/ac |
802.11a/b/g/n/ac |
Maximum Speed |
1.75 Gbit/s |
1.75 Gbit/s |
About the distribution:
As a golden distributor of HUAWEI, all of HUAWEI prodcucts from Polytrade/Sandes Technology are 100 % Original and Brandnew unless per clients’ requests; customers could claim 10time cost if you find we offer used or fake products. We offer one year warranty for all on-display products.
The HUAWEI products by us are whole series of hot-sell products, and if you did not find what you need on alibaba web, please contact us via sales[at] to gain supports.
