Home > Transportation > Specialized Vehicle > Garbage Truck > China 4x2 6m3 Capacity Small Garbage Compactor Truck

China 4x2 6m3 Capacity Small Garbage Compactor Truck

China 4x2 6m3 Capacity Small Garbage Compactor Truck photo-1
China 4x2 6m3 Capacity Small Garbage Compactor Truck photo-2
China 4x2 6m3 Capacity Small Garbage Compactor Truck photo-3
China 4x2 6m3 Capacity Small Garbage Compactor Truck photo-4
China 4x2 6m3 Capacity Small Garbage Compactor Truck photo-5
China 4x2 6m3 Capacity Small Garbage Compactor Truck photo-6
US$ 23,411 - 33,660 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Drive Wheel:
4x2
Type:
Recycling
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port Tianjin port Lianyungang port Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Drive Wheel 4x2
Type Recycling
Transmission Type Manual
Emission Standard Euro 4
Volume 1000 - 3000L
Fuel Type Diesel
Engine Capacity 4500
Size 6220(6320)*2140*2550
Gross Vehicle Weight 8495
Place of Origin Henan, China
Brand Name YUTONG
Model Number YTZ5080ZYS20F
Certification ISO
After-sales Service Provided Engineers available to service machinery overseas

China 4x2 6m3 Capacity small Garbage compactor truck

Product Description

Main Technical Parameters

Product model

YTZ5080ZYS20F

 China 4x2 6m3 Capacity small Garbage compactor truck

Chassis model

EQ1080SJ2BDA

Chassis manufacturer

Dongfeng Automobile Co., Ltd.

Overall dimension of complete vehicle (mm)

6270(6240, 6290)x2200x2610

Wheelbase (mm)

3100

Wheel track of front wheel (mm)

1770

Wheel track of rear wheel (mm)

1640

 China 4x2 6m3 Capacity small Garbage compactor truck

Kerb mass (kg)

6020,5650,5870

Rated load (Kg)

2280,2650,2430

Gross mass (kg)

8495

Maximum vehicle speed (km/h)

95

Maximum gradeability (%)

28

Maximum turning diameter (m)

13

 China 4x2 6m3 Capacity small Garbage compactor truck

Minimum ground clearance (mm)

200

Approach angle (°)

25

Departure angle (°)

12

Dustbin volume (m3)

6.0

Volume of precompressor (m3)

1.0

Compression cycle time (s)

20

 China 4x2 6m3 Capacity small Garbage compactor truck

Garbage dumping time (s)

35

Compression density (t/m3)

0.6-0.8

Color

optional

Product model

YTZ5080ZYS20F

Chassis model

EQ1080SJ2BDA

Chassis manufacturer

Dongfeng Automobile Co., Ltd.

 China 4x2 6m3 Capacity small Garbage compactor truck

Engine model

ISDe140 40

Rated power of engine

103 kw

Model of gearbox

1700010-C12031

Tyre

8.25-16 bias tire with regular pattern

Optional Configuration

Bucket hanging type turnover feeding mechanism

Dustpan-type turnover feeding mechanism

Performance

  Performance Characteristics

China 4x2 6m3 Capacity small Garbage compactor truck

1.The complete truck adopts domestic well-known Dongfeng Tianjin chassis that meets National III/National IV emission standard, providing economy, durability, elegant appearance and drive comfort.

2.The chassis power adopts National III/National IV engine produced by Cummins or Guangxi Yuchai, which has powerful power and high reliability and can meet the needs of different users.

3.The energy-efficient engine, with low fuel consumption and low noise, is economical.

4.The carriage body adopts the design technology of frameless arc-shaped bin. The arc-shaped side plates increase the rigidity and strength of the carriage body structure and the surface phosphorization and preservative treatment improve the carriage’s corrosion ability.

5. All plates of structural components are made of high strength manganese steel plate, extending the service life of the complete truck radically.

6.The guided sliding blocks of the dozer blade and the sliding plate are made of the high-density and high-intensity ultra-high molecular weight polyethylene materials, providing self-lubricating, anti-acid and alkali, high stiffness and no noise; the sealing strips are made of silicon rubber materials, which are aerotolerant, anti-aging and light resistant and have stable chemical stability.

7.These materials are not afraid of high temperatures and can resist cold weather.

8.The international leading hydrocylinder-driven locking arm technology has been applied to the precompressor locking
China 4x2 6m3 Capacity small Garbage compactor truck

9.The operation of locking the precompressor is easy and can be completed with one key.

10.The manual, automatic and mechanical control systems are available so that it is easy and reliable to operate, providing low failure rate and easy maintenance.

11.Dumping garbage can be controlled in the cab. The electrical system has been wired concealedly. The waterproof connectors have been used to ensure the safety and reliability of use.

12. The engine is provided with a throttle accelerator so that idle running and accelerated compression and unloading can be achieved in the process of the compression working cycle.

13. All plates of structural components are made of high strength manganese steel plate, extending the service life of the complete truck radically.

14.The hydraulic is characterized by a high degree of integration, easy operation, high performance and high response and so on; All the hydraulic cylinders are equipped with the imported Parker seals.
Our Services
China 4x2 6m3 Capacity small Garbage compactor truck

"12380"Service after sale. We can offer:

1.After receiving the customer mobile, we will help customer solve problem through removing the resources of
Yutong service and reply the customer clearly in one hours;

2: To improve the service quality all the time, in 2working days of the end of on-sit service, we will pay a return visit

about the satisfaction of after sale service;

3: To comprehensive systematically and professionally maintenance and repair for the customer product, we will

have 3 times On-Site Inspection forwardly in warranty period;

8:The service engineer will solve problem in 8 hours after getting to on-sit. If the problem is not solve ,the service

engineer can not leave the on-sit;

0: To eliminate customer worries, from receiving order to product scrapping, Yutong will provide full reliance,

seamless docking and service in the period of product using.
Garbage Solution
China 4x2 6m3 Capacity small Garbage compactor truck
Sanitation digital information management is a comprehensive application of computer technology, wireless network technology, GIS geographic information technology, GPS positioning technology, video surveillance technology, through the establishment of a unified management information system, to achieve the effect of environmental sanitation, environmental sanitation vehicles, sanitation, waste regulatory terminal disposal, as well as full control of the operating environment, capable of early detection of operational problems, a quick fix.
Company Information
China 4x2 6m3 Capacity small Garbage compactor truck
China 4x2 6m3 Capacity small Garbage compactor truck
China 4x2 6m3 Capacity small Garbage compactor truck
China 4x2 6m3 Capacity small Garbage compactor truck

Yutong Heavy Industry is China's top 500 enterprises Yutong Group's core subsidiary, is a leading supplier of specialized mining, infrastructure and sanitation machinery and equipment package of solutions. The company is the cradle of Chinese construction machinery design and manufacturing, since 1958, China's first hydraulic torque converter, the first power shift transmission, the first self-propelled scrapers, the first large horsepower tire type tractors, more than 30 "China's first" all born here! factory occupies 2102 acres, with more than 3,000 people, including more than 470 man-made construction machinery senior technical staff, and has academician workstation and provincial enterprise technology center.

Yutong Heavy Industries as a quality supplier of PLA, every year a large loaders and bulldozers to the military. We also provide the United Nations had as loaders, bulldozers and wreckers, and obtained the creation of the United Nations awarded the Star of Science Award.

 Our company is China's first loader KD line exporter, currently this KD line services in Iran, the annual amount of 300 assembly, and its products can cover the Middle East, many countries such as: Saudi Arabia, Turkey and Azerbaijan. Also Our rotary drilling rig, successfully sold to the United States five devices, and job conditions in Alaska minus 50 degrees. Our product is in Africa an affirmative president of Nigeria, the African business people and our next president our photo equipment. Our sanitation garbage package of solutions and services in Ghana is the country for the African brothers to improve their living environment contribute our part. In South America, Cuba and Venezuela, we are the government's long-term strategy for its suppliers. Rotary Drilling Division I Participation in 2008 Olympic Games in the Bird's Nest construction work, and successfully laid the first pile.


FAQ&Contact Us
  • Can you give us a brief introduction to Yutong Company please?

We are military equipment supplier, our original facotry is founded at 1958. Good quality and competitive price is our advantage.

  • How about the quality guarantee and after -sale service?

For quality guarate, we give one year guarantee, and with 24hours response principle for better service.

We have more than 30 agency all over the world, you can get the most convenient service by nearest agency.

  • How about the payment terms?

We accept T/T, L/C, D/P, D/A,even L/G.

China 4x2 6m3 Capacity small Garbage compactor truck
