Specifications
1.PWM Dimmer, 24 Volt, 8A (192W)2.high qulity & competitive price
3.PCBA ODM OEM
PWM Dimmer, 24 Volt, 8A (192W) Instructions & Specifications:
This dimmer is designed to operate LED lighting, such as LED Light Strips and other light sources. It has an integral on/off switch and provides precise dimming of light sources.
To install, use the screw terminals and/or attached input and output wires (shaft is 1/4"). Take care to ensure the dimmer does not contact surrounding metal structure or other wiring.
Specifications
Mode of Operation - Continuously variable, pulse width modulation (PWM).
Supply Voltage - 8 to 30VDC working voltage, up to 35VDC momentary.
Output Voltage Range - From zero VDC to supply voltage
Output Current Range - Up to 8A
Ambient Temp Range - minus 40F (-40C) to 115F (46C), with restrictions as noted
DC-DC Conversion Efficiency - About 98% at full rated current, higher at lower current
Load Types - Optimized for resistive loads
Size–67*39*25(mm)
Weight–30 to 40 gm,
Load Regulation - Generally less than 3% from minimum load to maximum load at all settings
Line Regulation - Directly proportional to supply voltage
Power Dissipation of Drive Circuitry - Less than 0.038W. No load current draw is about 1mA. Nil current used if on/off switch is in Off position.
Accessories - Knob
Refer pictures:
