Specifications
1. Dimmerable LED Power Supply / LED Driver2. ODM and OEM is availble
3. High qulity & compective price
Our company is specalized in pcb design, pcb manufacture and assembly ODM/OEM service. LED dimmer is one of our main self-designed products.
12V6A PWM led dimmer
Function:
on/off switch switch ; precise dimming of light stuff.
Specifications:
Mode of Operation :Continuously variable, pulse width modulation (PWM).
Supply Voltage :8 to 20VDC working voltage, up to 30VDC momentary.
Output Voltage Range :From zero VDC to supply voltage
Output Current Range :Up to 8A
Ambient Temp Range :minus 40F (-40C) to 115F (46C), with restrictions as noted
DC-DC Conversion Efficiency :About 98% at full rated current, higher at lower current
Load Types :Optimized for resistive loads
Size :61*37*25(mm)
Weight :20 to 30 gm
Load Regulation : Generally less than 3% from minimum load to maximum load at all settings
Line Regulation :Directly proportional to supply voltage
Power Dissipation of Drive Circuitry :Less than 0.038W. No load current draw is about 1mA. Nil current used if on/off switch is in Off position.
Installation:
To install, use the screw terminals and/or attached input and output wires (shaft is 1/4").
Take care to ensure the dimmer does not contact surrounding metal structure or other wiring.
Other models :
Our company:
Any interest, please do not hesitate to contact us.
