2 Color Flexographic Plastic Print Press/Plastic Printing Machine

Specifications

1.it can print roll plastic film, such as PP,PE,PVC,BOPP
2.easy operation
3. flexible starting
4.accurate color register

YT-2600 two colors flexographic printing machine





Feature:



1.1The meter counter can set printing quantity according to the requirements,stop the machine automatically at the quantity or when the material is cut off.



1.2 Pneumatic printing cylinder lift and lower, it will stir the printing ink automatically after lifting.



1.3 The printing ink is spread by the anilox cylinder with even ink color.



1.4 Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.360continuous and adjustable longitudinal register device.



1.5 The frequency control of motor speed adapts to different printing speeds.



1.6 Suitable for printing the packing material as PE and PP plastic bags,glass papers rolling papers,etc.









Main Technical Specification





Model	YT-2600	YT-2800
Max printing web width	600mm	800mm
Max printing width	560mm	760mm
Length of printing product	191-960mm	191-960mm
Diameter of Roll Material	φ450mm	φ450mm
Printing Speed	5-50m/min	5-50m/min
Thickness of printing Plate	2.38mm	2.38mm
Total power	8.5kw	11.2kw
Overall Dimension	2300×1600×2200mm	2300×1800×2200mm
Weight	1800kg	2000kg

Picture Show













Packing and Loading
