Help CenterLeadingtouch 22" Multitouch Infrared IR Touch Monitor Kiosks TM-2258
Related Products
-
IR Touch Open Frame Touch Monitor 15"/17"/19"/19"W/22"US$ 250 - 300MOQ: 1 Unit -
Leadingtouch Mulitouch IR Touch Monitor 12"-65"US$ 200 - 1,000MOQ: 1 Unit
-
Multi Touch IP65 Touch Monitor 15"/17"/19"US$ 350 - 450MOQ: 1 Unit
-
Multitouch IR Touch Open Frame Touch Monitor 22"/24"/26"/32"/42"/55"/65"NegotiableMOQ: 1 Unit
-
Leadingtouch Open Frame Multi Touch Monitor 22"/24"/26"/32"/42"/55"/65"US$ 700 - 900MOQ: 1 Unit
Specifications
1, Multitouch IR Infrared waterproof IP65 touch bezel2, Dual RS232 and USB combo touch;
3, Compatibile ELO model:ET2239L
Agency Approval:Leadingtouch touchscreens, controllers, and cables have been approved for CE marking. Where appropriate, Touchmonitors are marked CE compliant, and are typically Class B. Systems incorporating leadingtouch touchscreens, controllers, and cables have been approved to FCC Class A compliance. Touchmonitors typically are FCC Class B verified RoHS
Model |
TM-2258 |
Description |
22″wide screen TFT Rear Mount Touchmonitor |
Case/Bezel Color |
Plastic / Black |
Display |
16:10 Ratio Active matrix TFT LCD |
Optimal(native) resolution |
1680 x 1050 @ 60Hz |
Sychronization Range |
72.1 KHz horizontal, 60 Hz vertical |
Useful screen area |
300.1mm x 477.7mm |
Colors |
16.7 million |
Brightness |
LCD panel: 300cd/m2 (typical) |
| |
With IR touchscreen: 280 cd/m2 (typical) | |
Pixel Pitch |
0.282 x 0.282 mm |
Response Time |
5 msec (typical) |
Contrast ratio |
1000:1 typical |
Viewing angle(typical, from center) |
Horizontal (left/right): 170°(85° /85° ) |
Vertical (up/down): 160°(80° /80° ) | |
Backlight Lamp life |
50,000 Hrs to 1/2 brightness |
Input video format |
Analog (VGA) and DVI |
Input video signal connector |
Analog (VGA) and DVI |
On Screen Display(OSD) |
Remote OSD with 1.2m Cable |
Touch Technology |
Multitouch IR Infrared Touch Panel |
Touch Interface |
Combo 10ms 232 and USB interface |
Touch Resistive Time |
10ms |
Mounting Options |
Rear Fixed, 100mm VESA mount |
Power supply |
External:100-240V AC, 50-60 Hz |
Power Consumption |
31W Typical |
Temperature Range |
Operating:0ºC-50ºC, Storage:-20ºC-60ºC |
Humidity Range |
Operating:8%-90%, Storage 5%-90% |
Touchmonitor Dimension |
530 x 352 x 73(mm) |
Shipping Carton Dimension |
630x 452 x 190(mm) |
Weight(approx.) |
Monitor:7kg / shipping: 10kg |
Warranty |
Monitor: 3 years/’; LCD Panel: 1 year |
Agency Approvals |
FCC, CE, RoHS compliant |
