Home > Consumer Electronics > Display & Accessories > Touch Screen > Leadingtouch Mulitouch IR Touch Monitor 12"-65"

Leadingtouch Mulitouch IR Touch Monitor 12"-65"

Name: Leadingtouch Mulitouch IR Touch Monitor 12"-65"
Brand: LeadingTouch
SKU: 117870155

US$ 200 - 1,000 MOQ: 1 Unit

Key Specifications

Screen Size:

Other, 15"

Type:

Infrared

Interface Type:

D-Sub, DVI, Serial, USB

Leadingtouch Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai China

Delivery Detail:

Delivery time depends on order quantity.

Screen Size Other, 15"

Type Infrared

Interface Type D-Sub, DVI, Serial, USB

Resolution 1280 x 1024

Brand Name LeadingTouch

Model Number TM-1518

Place of Origin Beijing, China

Model	TM-1518
Description	15” TFT Desktop Touchmonitor
Case/Bezel Color	Black
Display	4:3 Ratio Active matrix TFT LCD
Optimal(native) resolution	1024X768@60Hz
Sychronization Range	Horizontal:30-80 kHz; Vertical: 56.3-75Hz
Useful screen area	Horizontal: 11.93" (303 mm);Vertical: 8.96" (227.6 mm)
Colors	16.7 million
Brightness	LCD panel: 250 cd/m2 (typical) with touchscreen: 230 cd/m2 (typical)
Brightness	With touchscreen: 230 cd/m2 (typical)
Pixel Pitch	0.297 x 0.297 mm
Response Time	16 msec (typical)
Contrast ratio	450:1 typical
Viewing angle(typical, from center)	Horizontal (left/right): 120°(60° /60° )
Viewing angle(typical, from center)	Vertical (up/down): 100°(50° /50° )
Backlight Lamp life	50,000 Hrs to 1/2 brightness
Input video format	VGA or DVI optional
Input video signal connector	Mini D-Sub 15-Pin VGA type
On Screen Display(OSD)	Multilingual OSD
Touch Technology	Multitouch IR touch
Touch Interface	Combo 10ms232 and USB interface
Touch Resistive Time	10ms
Mounting Options	Rear Fixed, 75 mm VESA mount, removable tilt base
Power supply	External:100-240V AC, 50-60 Hz
Power Consumption	50W max
Temperature Range	Operating: 0°C to 50°C; Storage: -20°C to 60°C
Humidity Range	Operating: 20%-85%; Storage: 10%-95%
Touchmonitor Dimension	Without Base: 400 x 330 x 64(mm) With Base: 400 x 370 x 210(mm)
Shipping Carton Dimension	450x 370 x 155(mm)
Weight(approx.)	Monitor: 4.8kg / shipping: 7kg
Warranty	Monitor: 3 years’; LCD Panel: 1 year
Agency Approvals	FCC, CE, RoHS compliant
