Help CenterTouch Query All-in-one Computer 6.4inch Wall-mounted Touch One Machine TKUN
Related Products
-
Touch Screen Query All-in-one Outdoor Anti Glare and Anti Reflection 13.3 Inch With J6412 RS232 LAN USBUS$ 575 - 580MOQ: 1 Pack -
13.3inch Touch Sensitive Industrial Tablet Computer, Industrial Control Computer With RS232 LAN SIM Card SlotUS$ 575 - 580MOQ: 1 Bag
-
10.1inch Touch Sensitive Industrial Tablet Computer Windows Touch Screen All-in-one With RS232 LAN SIM Card SlotUS$ 508 - 510MOQ: 1 Bag
-
13.3inch Marine High Brightness Touch Integrated Computer 16：9 With RS232 LAN SIM Card SlotUS$ 575 - 580MOQ: 1 Bag
-
TKUN15inch Capacitive Touch Screen All In One Pc LCD Touch Screen All-in-one Machine With RS232 LAN SIM Card SlotUS$ 528 - 530MOQ: 1 Bag
Display Pane |
Brand |
TKUN |
Size/Proportion |
6.4 inch 4:3 |
|
Model |
N064CC |
|
Brightness |
450cd/㎡ |
|
Resolution |
1024*768 |
|
Contrast |
1000:1 |
|
Display color |
16.7M |
|
Response time |
2-5ms |
|
Visible angle |
85/85/85/85(Typ.CR≥10) |
|
Pixel pitch |
0.12675(H)X 0.12675(V)mm |
|
Draw quality |
3D noise reduction, high-definition signal, progressive scan |
|
Touch Function |
Touch screen |
Capacitive touch screen (10 points) |
Surface hardness |
≥6h |
|
Transmittance |
＞95% |
|
Positioning accuracy |
less than 2mm |
|
Click lifetime |
> 60 million times |
|
Touch medium |
Current sensing, capacitive touch pen, finger |
|
Right-click function |
click on a certain point and press for more than 3 seconds |
|
Touch interface |
USB |
|
|
Motherboard Function
|
Mainboard |
TKUN industrial motherboard |
CPU |
Intel Celeron J6412 Quad-core |
|
the cpu frequency is 2.0ghz，Max Speed Up to 2.6GHz | ||
Secondary cache 1.5 MB L2 Cache |
|
Display card
|
integrated graphics |
Intel® UHD Graphics for 10th Gen Intel® Processors |
|
basic frequency of graphics card |
400MHz |
||
maximum dynamic frequency |
800MHz |
||
System |
Windows 10 IoT Enterprise（support Windows11，Linux，UOS） |
||
RAM |
4G (optional 8G/16G/32G) |
||
SSD |
128G(optional 256G/512G/1T/2T) |
||
LAN |
LAN*2 Intel® 10M/100M/1000M/2.5Gbps adaptive |
||
USB |
USB3.0*4 |
||
COM |
RS232(485)*4 （customizable RS422） |
||
HDMI |
HDMI*1 |
||
SIM |
SIM*1 |
||
Wireless Network |
Wireless card |
Wifi is not available as standard (optional) |
|
Open Close |
Power |
Power*1 (power-on and power-on function can be set) |
|
Power Input |
AC/DC |
DC9-36V |
|
Watchdog |
Watch dog timer |
0-255 seconds, providing watchdog routine |
|
|
Product Power |
Power |
≤20W |
|
Environment |
Operating temperature/humidity |
-20℃ to +70℃/ 0-80% relative humidity, no condensation |
|
|
Storage temperature/humidity |
-40℃ to +80℃/0-90% relative humidity, no condensation |
||
Vibration resistant |
30Hz, X, Y, Z axis 60 minutes each |
||
Esd protection |
Class 3, contact discharge ± 6KV, air discharge ±8KV |
||
Panel level |
IK6 |
||
Safety regulations |
Test standards |
IEC60601 |
|
|
Equipment Usage |
Application area |
Military equipment, aerospace equipment, rail transit/communication, professional photography display, smart supermarket, smart robot, smart meeting room, factory assembly linePOS cash register, car GPS, elevator entrance, commercial office building, exhibition site, etc. occasion |
|
|
Equipment Cleaning |
Cleaning method |
Spray the screen cleaning liquid or clean water on the surface of the soft lens cloth to wipe the screen. Do not use alcohol, strong acid, or strong alkali to wipe the screen. The shell can be wiped with a soft towel or lens cloth. |
|
|
Product Service |
After service |
one-year warranty and lifelong maintenance |
|
Customized service |
OEM/ODM is available for material, appearance, dimensions, wide temperature, outdoor highlight, wide voltage, etc. |
||
