Rohde & Schwarz FSEB30 /K10/K11/B4/B5/B7/B15 Spectrum Analyzer
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Florida, United States
Brand Name:
Rohde & Schwarz
Model Number:
FSEB30
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Rohde & Schwarz FSEB30 /K10/B4/B5/B7/B15 Spectrum AnalyzerNegotiableMOQ: 1 -
Anritsu S331D-03 Site Master Cable and Antenna AnalyzerNegotiableMOQ: 1
-
Tektronix RSA3303B; 3 GHz Real Time Spectrum Analyzer, 15 MHz BandwidthNegotiableMOQ: 1
-
Agilent / Keysight E4991A -001-002-1D5 RF Impedance/Material AnalyzerNegotiableMOQ: 1
-
Rohde & Schwarz FSEA30/B4/B5 3.5GHz Spectrum AnalyzerUS$ 7,800 - 8,100MOQ: 1 Unit
Place of Origin
Florida, United States
Brand Name
Rohde & Schwarz
Model Number
FSEB30
Specifications
Rohde & Schwarz FSEB30 /K10/K11/B4/B5/B7/B15 Spectrum AnalyzerThe Rohde & Schwarz FSEB30 is a 20Hz to 7GHz, Spectrum Analyzers. The FSE spectrum analyzers from Rohde & Schwarz have been optimized both for general-purpose measurements and meeting the stringent requirements of testing advanced digital communication systems.
- Spectrum analysis with ultra-wide dynamic range Noise figure = 18 dB/TOI = 20 dBm typ.
- Universal analysis of digital and analog modulated signals (option) such as BPSK, QPSK, π/4-DQPSK, 8PSK, QAM, MSK, GMSK, 2FSK, AM, FM, PM
- High-speed synthesizer 5 ms for full span
- Refresh rate, quasi-analog 25 sweeps/s
- Large LC TFT display 24 cm/9.5", active
- Future-proof modular design Customized solutions through wide variety of options
- Displayed noise floor –150 dBm (typ.) in 10-Hz bandwidth
- 3rd-order intercept point +20 dBm typ.
- 1 dB compression point of RF input +10 dBm
- Sweep time: Span = 0 Hz - 1 µs to 2500 s in 5% steps; Span ≥10 Hz - 5 ms to 16 000 s in steps ≤10% ;Error limit <1%
- Sampling rate 50 ns (20 MHz A/D converter)
- Number of pixels 500
- AF demodulation types - AM and FM
Options:
- K10 - GSM Application S/W (Mobile)
- K11 - GSM Application S/W (BTS)
- B4 - Low Phase Noise
- B5 - FFT Filter
- B7 - Vector Signal Analyzer
- B15 - Computer Function Capability w/mouse and keyboard
