Agilent/HP 8563E -007 Portable Spectrum Analyzer With Calibration
US$ 9,500 - 9,750
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Florida, United States
Brand Name:
Agilent
Model Number:
8563E -007
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Agilent/HP 8563E -007 Portable Spectrum Analyzer With CalibrationUS$ 9,500 - 9,750MOQ: 1 Unit -
Rohde & Schwarz FSH6.06 100kHz to 6GHz Portable Spectrum AnalyzersNegotiableMOQ: 1
-
Agilent/HP 3588A Spectrum AnalyzerNegotiableMOQ: 1
-
Agilent 8596E-004-041-101-105 Spectrum AnalyzerNegotiableMOQ: 1
-
Agilent/HP 8595A/004/010/021 9kHz-6.5 GHz Spectrum AnalyzerNegotiableMOQ: 1 Unit
Place of Origin
Florida, United States
Brand Name
Agilent
Model Number
8563E -007
Specifications
Agilent/HP 8563E -007 Portable Spectrum Analyzer, 9kHz to 26.5 GHz.The Agilent 8563E portable microwave spectrum analyzer offers the measurement capability and performance previously found in larger, more expensive benchtop analyzers. This analyzer has a standard frequency range of 9 kHz to 26.5 GHz (preselected from 2.75 GHz to 26.5 GHz), with optional low-end frequency coverage to 30 Hz.
The 8563E combines outstanding phase noise, sensitivity, 1 Hz resolution bandwidths, synthesized tuning and wide dynamic range in a MIL-rugged package built to withstand harsh environmental conditions.
.
Key Features and Specifications
- Continuous 30 Hz to 26.5 GHz sweep
- Fast digital resolution bandwidths of 1, 3, 10, 30 and 100 Hz
- Adjacent channel power, channel power, carrier power, occupied bandwidth percentage and time-gated measurements standard
- Precision timebase and 1 Hz counter resolution
- MIL-T-28800 rugged
- Measurement personalities for digital radio and phase noise measurements
Option:
- 007 - Digitized fast time domain sweeps
Unit has a refurbished LO distribution amplifier, a New RYTHM Tower, a Newly rebuilt power supply,
The entire unit has been adjusted and aligned then calibrated.Purchase Includes:
- 30 Day Warranty
- 7 Day Right of Return
- Power Cord
- Calibration with Certificate
- CD Manuals
