Cyanidation Machine
- QINGDAO/SHANGHAI
- T/T
You May Like
-
Basalt sand making machine price,sand maker
-
Sample Structure Cyanidation Machine Spiral Classifier
-
Good Quality Vanadium Titanium Magnetite Magnetic Processing Plant
-
High Efficient Niobium and Tantalum Lithium Beryllium Flotation Processing Plant
-
High Manganese Steel Hammer Head Fine Crusher
-
platinum group cyanidation processing plant
Product Details
| Place of Origin | Henan, China | Brand Name | Donxe | |
| Model Number | NZSG-3 | Condition | New | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.good flocculation2.flexible automatic control system
3.long operating life
Description of Efficiency Thickener
Thickener is gravity sedimentation equipment to separate liquid-solid mixture of homogeneous phase.The thickener collects slurry to center by scraper and then discharges from the outlet.
It is extensively used in industries, such as thickener applied in mineral processing plant, separating fine mineral from water, thickener applied in chloride-alkali plant to separate salt mud, thickener applied in waste water processing plant, and wet process phosphorus acid etc. Meanwhile,NHD-serial deep cone thickener is developed and successfully applied in alumina for red mud separating and washing system to increase solid content in red mud, which bring treatment of alumina tailings into a new stage.
Performance Characteristics of Thickener
The High efficiency concentrator machine of our company is suitable for dehydrating water of the concentration and gangue in the concentrating factory which can make the mash of 20-30% raise up to 40-70% about. It is widely used for melting, chemical, coal, non metal concentration, environment protected etc industry.
Working Principle of Thickener
This thickener consists of round thickener and harrow scrapping machine, the solid particles suspend in thickener settling by gravity, the pulp in the upper turn into clean water, so that the separation can be realized. Slime that sediment in the bottom of the thickener is discharged by the harrow scrapping continuously, and clean overflow from the upside.
Technical Parameters of Efficiency Thickener:
Model | D of the tank(mm) | Depth of | Sedimental area(m2) | Capacity(t/d) | Motor model | Motor | Weight of the tank(kg) | Weight(kg) |
NZSG-2.5 | 2500 | 1850 | 4.9 | 5-22.4 | Y90L-6 | 1.1 | 1000 | 2225 |
NZSG-3A | 3000 | 1800 | 7 | 5-23.3 | Y100L-6 | 1.5 | 1664 | 3168 |
NZSG-3 | 3600 | 1800 | 10.2 | 5-28.5 | Y100L-6 | 1.5 | 2097 | 3640 |
NZSG-5 | 5000 | 2956 | 16 | 16-90 | Y90L-4 | 1.5 | 5160 | 8031 |
NZSG-6 | 6000 | 2956 | 28.3 | 98 | Y90L-4 | 1.5 | 5769 | 9200 |
NZSG-7 | 7000 | 3000 | 38.5 | 140 | Y112M-6 | 2.2 | 8548 | 13361 |
NZSG-8 | 8000 | 3318 | 50.2 | 185 | Y132S-6 | 3 | 12966 | 19289 |
NZSG-9 | 9000 | 3376 | 63 | 210 | Y132S-6 | 3 | 15304 | 21960 |
NZSG-12 | 12000 | 3600 | 113 | 370 | Y132S-6 | 3 | 25389 | 34823 |
NZSG-15 | 15000 | 4000 | 176 | 580 | Y132M2-6 | 5.5 | 35800 | 58800 |
NZSG-18 | 18000 | 4400 | 255 | 960 | YCT200-413 | 7.5 | 51000 | 75600 |
NZSG-20 | 20000 | 4400 | 315 | 1400 | Y160M2-8 | 7.5 | 62000 | 83550 |
• one year guarantee for whole machine except man-made damage.
• technical support by e-mail on workday
•during the installation and commissioning, the seller shall send technician to the site for instruction of installation and commissioning, and for training of workers.
• the buyer shall afford the travelling expense (including the expense of airline ticket, train ticket, board and lodging); the buyer shall also pay the service fee of USD 80/day/person.
• If there is any equipment failure caused by the buyer, the seller shall assist the maintenance of machines and replacement of fittings, and charges appropriate fees.
Packaging Details:
1.Outside package:Standard wooden case or bare packaging
2.Inner package: stretch film
Delivery Detail:
about 25 workdays after payments
