Autoamtic Flute Laminator
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Laminating Machine
Computerized:
Yes
Place of Origin:
Shanghai, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Automatic Flute Laminating MachineNegotiableMOQ: 1 Unit -
Automatic Film LaminatorNegotiableMOQ: 1 Unit
-
Automatic Film Laminating Machine (Water-based)NegotiableMOQ: 1 Unit
-
Automatic Film Laminating MachineNegotiableMOQ: 1 Unit
-
Automatic Sheeter After Film Laminator ( for Film Laminated Sheet in Roll)NegotiableMOQ: 1 Unit
Type
Laminating Machine
Computerized
Yes
Place of Origin
Shanghai, China
Brand Name
Towin
Model Number
FMZ-1300/1450/1600
Specifications
1.Automatic flute laminator2.Laminator for carton and corrugated board
3.Laminator for corrugated board and corrugated board
Applications
The machine is used for lamination between bottom carton sheet and top carton sheets or A/B/C/D/E flute corrugated board and also the lamination between both corrugated boards
Features
- Automatic top and bottom sheet feeding with pre-load device for top sheet;
- Man-machine interface with PLC gives easy operation and trouble shooting indications during machine running. Safety covers are put into consideration during machine design for operator safety.
- Key bearings and electrical components adopt famous international brand, which ensures high running and control accuracy.
- Elastic front lay ensures bottom sheet does not exceed the top one. The front-and-back overlapping margin of top and bottom sheets is adjustable.
- The machine is suitable for lamination between bottom carton sheet over 350gsm and top carton sheets or A/B/C/D/E flute corrugated board and also the lamination between both corrugated boards.
Technical specifications
Model |
FMZ-1300 |
FMZ-1450 |
FMZ-1600 |
Max.sheet size |
1300×1100mm |
1450×1100mm |
1600×1200mm |
Min.sheet size |
400×400mm |
400×400mm |
400×400mm |
Total electric consumption |
15kw |
15kw |
15kw |
Substrate of top sheet |
≥200GSM |
≥200GSM |
≥200GSM |
Laminating tolerance |
±1.5mm |
±1.5mm |
±1.5mm |
Max.speed |
5000sph |
5000sph |
5000sph |
Machine weight |
5.8 tons |
6.5 tons |
7.2 tons |
Overall Dimensions |
11500×1900×2500mm |
11500×2100×2500mm |
11500×2450×2500mm |
