Automatic Film Laminating Machine (Water-based)

Automatic Film Laminating Machine (Water-based) thumbnail-1
Automatic Film Laminating Machine (Water-based) photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
Towin, Towin
Model Number:
Model FMR-740/1100, FMR-740/1100
Contact Supplier Request Quote Chat Now
Shanghai Towin Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name Towin, Towin
Model Number Model FMR-740/1100, FMR-740/1100

Specifications

1.Ecnomic film laminating machine
2.Good lamination accuracy
3.Auto feeder available
4.Laminated sheets collected in roll

Features:

1.Feeding by auto feeder gives high efficiency.

2.Accurate front and side lays give perfect sheet registration to ensure good laminating accuracy.

3. Overlapping margin of two sheets is adjustable. This gives wide applications.

4.Immerging type coater makes coating more even and saves glue.

5.Equipped with precise auto punching device and auto film cutting device.

6.Auto counter, auto no-sheet stop and auto glue supplying system are available.

7.Air suction sheet feeding system to avoid sheet deflection.

Technical specifications:

Model

FMR-Z740

FMR-Z1100

Max.Sheet size

740X540mm

1020X740mm

Min.Sheet size

546X340mm

546X340mm

Substrate

125-450gsm

125-450gsm

Laminating speed

0-50m/min

0-50m/min

Sheet overlapping tolerance

±3mm

±3mm

Total power

6.5kw

6.5kw

Machine weight

1800kg

2000kg

Machine dimension(LxWxH)

3700X1250X1750mm

3700X1650X1750mm
