the profect and low price china well high speed gap lathe
- 30 Set / Sets per Month
- shanghai.china
- T/T L/C D/P D/A
- Small CNC Lathe, Metal turning machine, industrial machine, metal working cnc
- Small CNC Lathe, Metal turning machine, industrial machine, metal working cnc, turn-mill machine
- Small CNC Lathe, Metal turning machine, industrial machine, metal working cnc
- Small CNC Lathe, Metal turning machine, industrial machine, metal working cnc, turn-mill machine
- Small CNC Lathe, Metal turning machine, industrial machine, metal working cnc
- Small CNC Machine Vocation School CNC Lathe Hobbist CNC Machine
Product Details
Condition: | New | CNC or Not: | Normal | Automatic Grade: | Semi-Automatic |
Max. Swing Diameter: | 500mm | Place of Origin: | Jiangsu, China | Brand Name: | ALMACO |
Model Number: | LB6250C | Voltage: | 380V | Power(W): | 7.5kw |
Dimension(L*W*H): | 2632*975*1270mm | Weight: | 2100/2300kg | Certification: | CE;ISO |
Product Description
china gap lathe LB6250C
Special Accessories:
1.Chip guard
2.Big steady rest
3.Big follow rest
4.Taper turning attachment
5.Automatic feed stop
6.Quick change tool post
7.Tool cover and chuck cover
8.Protection for leadscrew
Standard Accessories
1.3-jaw chuck and adapter
2.Center sleeve and center
3.Tools
4.Oil gun
5.Operation manual
6.Drive plate
7.Steady rest
8.Follow rest
9.Thread chasing dial
10.Foot brake
11.Coolant system
12.Light system
13.4-jaw chuck
china gap lathe LB6250C
SPECIFICATIONS | UNIT | LB6240 | LB6250/B | LB6266/B | LB6280B | LB6250C | LB6266C | LB6280C | |
Capacity | Max. swing dia. over bed | mm | Ø400 | Ø500 | Ø660 | Ø800 | Ø500 | Ø660 | Ø800 |
Max. swing dia. in gap | mm | Ø630 | Ø710 | Ø870 | Ø1000 | Ø710 | Ø870 | Ø1000 | |
Max. swing dia. over slides | mm | Ø220 | Ø300 | Ø420 | Ø560 | Ø300 | Ø420 | Ø560 | |
Max. workpiece length | mm | 750/1000/1500/2000/3000 | 1000/1500 2000/3000 | 2000/3000 | 1000/1500 2000/3000 | 2000/3000 | |||
Spindle | Spindle bore diameter | mm | Ø52 | Ø82 | Ø82 | Ø105 | |||
Type of spindle nose | CS6240: ISO 702/III No. 6 bayonet lock; others: ISO 702/Π NO.8 com-lock type | ||||||||
Spindle speed | rpm | 24 steps 9-1600 | 24 steps 8-1400 | 12 steps 36-1600 | 12 steps 30-1400 | ||||
Spindle motor power | KW | 7.5 | |||||||
Tailstock | Diameter of quill | mm | Ø75 | Ø90 | Ø90 | ||||
Max. travel of quill | mm | 150 | |||||||
Taper of quill (Morse) | MT | 5 | |||||||
Turret | Tool O.D. size | mm | 25 x 25 | ||||||
Feed | Max. X travel | mm | 145 | ||||||
Max. Z travel | mm | 320 | 310 | 320 | |||||
X feed range | mm/r | 93 kinds 0.028-6.43 | 65 kinds 0.063-2.52 | ||||||
Z feed range | mm/r | 93 kinds 0.012-2.73 | 65 kinds 0.027-1.07 | ||||||
Metric threads | mm | 48 kinds 0.5-224 | 22 kinds 1-14 | ||||||
Inch threads | t.p.i | 48 kinds 72-1/4 | 25 kinds 28-2 | ||||||
Module threads | πmm | 42 kinds 0.5-112 | 18 kinds 0.5-7 | ||||||
Diametric pitch threads | t.p.i.π | 42 kinds 56-1/4 | 24 kinds 56-4 | ||||||
Other | Cooling pump motor power | KW | 0.06 | ||||||
Length | mm | 2382/2632/3132/3632/4632 | 2632/3132 3632/4632 | 3365/4365 | 2632/3132 3632/4632 | 3365/4365 | |||
Width | mm | 975 | 1050 | 1340 | 975 | 1340 | |||
Height | mm | 1230 | 1350 | 1460 | 1270 | 1450 | 1490 | ||
Weight | Kg | 1795/2050 2250/2450/2850 | 2050/2100 2300/2500/2900 | 2400/2600 2800/3000 | 3300/3700 | 2100/2300 2500/2900 | 2200/2400 2600/3000 | 3000/3200 |
china gap lathe LB6250C
Welcome to Almaco Machine Tool Co., Ltd
our company as the main partner member of China Jiangsu International Economic-Technical Cooperation Corporation,specializes in import & export of brand-new industrial machinery & tools.Our mechanical products with ISO9001 or CE certificate cover more than 80 kinds including lathe ,milling machine,grinding machine,power press,guillotine shearer,hydraulic press brake,CNC Machine and so on,which have been exported to 40 or more countries & areas.
The machines are packed with wooden case or depend on your requires.
Regarding to the shipping, the machine will be deliveried to your destination ports or place you assign
Our engineer team
*******************************************************************************************************
1.All of our goods will pass QUALITY INSPECTIONS before shipment.Best after sale service, customer can follow their order situation any time, no matter on product line, warehouse or shipment.
2.More than 5 years experience in exporting to make your order more smooth.Less than one container loading is accepted.
On time delivery, in general 30 days. Multimode payment:T/T,L/C.
3.Special dimensions available according to request.
4.We have many certificates of our Products.
5.Accessories replacement if our product itself has quality problems during one year after receiving.
