Product Details
Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | almaco |
Model Number: | DMC7020 | CNC or Not: | Normal | Voltage: | 380V |
Power(W): | 0.75kw | Dimension(L*W*H): | 880*770*1140mm | Weight: | 270/300kg |
Certification: | CE;ISO9001 | Warranty: | CE;ISO9001 |
Product Description
mini drilling machine DMC7020
standard accessories:
1.Allen wrenches 3,4,5,6mm
2.wedge
3.wrench
4.drill stock
5.screw drive 6''
6.drawbar washer
Optional accessories:
1.machine stand
2.power feed attachment
3.paraller vice
4.drill chuck
5.milling cutter holder
6.change sleeve
7.milling chuck
8.boring bar
9.auto-tapping electrical system
mini drilling machine DMC7020
mini drilling machine DMC7020
odel | ZAY7045 ZAY7045G ZAY7045G | ZAY7040 ZAY7040G ZAY7040FG | ZAY7032 ZAY7032G ZAY7032FG | ZAY7020 ZAY7020G | |
Drilling capacity | 45mm | 40mm | 32mm | 20mm | |
Face milling capacity | 80mm | 80mm | 63mm | 63mm | |
End milling capacity | 32mm | 32mm | 20mm | 14mm,20mm | |
Distance from spindle nose to table | 450mm, 680mm | 450mm, 680mm,440mm | 450mm, 680mm,440mm | 382mm,350mm | |
Min. distance from spindle axis to column | 193.5mm,272.5mm,260mm | 193.5mm,272.5mm,260mm | 193.5mm,272.5mm,260mm | 202mm,175mm | |
Spindle travel | 130mm | 130mm | 130mm | 120mm,130mm | |
Spindle taper | M.T.4 or R8 | M.T.4 or R8 | M.T.3 or R8,M.T.4 or R8 | M.T.3 | |
Step of spindle | 12,6 | 12,6 | 12,6 | 12,6 | |
Range of spindle speed | 50Hz | 80-2080,80-1250r.p.m. | 80-2080,80-1250r.p.m. | 80-2080,80-1250r.p.m. | 80-2080,80-1250r.p.m. |
60Hz | 100-2500,95-1500r.p.m. | 100-2500,95-1500r.p.m. | 100-2500,95-1500r.p.m. | 100-2500,95-1500r.p.m. | |
Swing diameter of headstock | 405mm,680mm, | 405mm,680mm | 405mm,680mm | 405mm,680mm | |
Swivel angle of headstock | horizontally | 3600 | 3600 | 3600 | 3600 |
perpendicularly | +900 | +900 | +900 | +900 | |
Size of table | 800 x 240mm2, 700x 240mm2 | 800 x 240mm2, 700x 240mm2 | 800 x 240mm2, 700x 240mm2 | 585 x 190mm2 | |
Forward and backward travel of table | 175mm | 175mm | 175mm | 150mm | |
Left and right travel of table | 500mm, 400mm | 500mm, 400mm | 500mm, 400mm | 380mm | |
Power | 1.5kw (2Hp) | 1.1kw (2Hp),1.1kw(0.75Hp) | 0.75kw (1Hp) | 0.75kw (1Hp),0.55kw (1Hp) | |
Voltage/Fequency | As custmers requirement | As custmers requirement | As custmers requirement | As custmers requirement | |
Overall height (Without stand) | 1060mm; 1300mm;1020mm | 1060mm; 1300mm;1020mm | 1060mm; 1300mm;1020mm | 1060mm; 1300mm | |
Net weight | 285kg,320kg,325kg | 283kg,318kg,323kg | 280kg,315kg,323kg | 270kg,300kg |
Welcome to Almaco Machine Tool Co., Ltd
our company as the main partner member of China Jiangsu International Economic-Technical Cooperation Corporation,specializes in import & export of brand-new industrial machinery & tools.Our mechanical products with ISO9001 or CE certificate cover more than 80 kinds including lathe ,milling machine,grinding machine,power press,guillotine shearer,hydraulic press brake,CNC Machine and so on,which have been exported to 40 or more countries & areas.
The machines are packed with wooden case or depend on your requires.
Regarding to the shipping, the machine will be deliveried to your destination ports or place you assign
Our engineer team
*******************************************************************************************************
1.All of our goods will pass QUALITY INSPECTIONS before shipment.Best after sale service, customer can follow their order situation any time, no matter on product line, warehouse or shipment.
2.More than 5 years experience in exporting to make your order more smooth.Less than one container loading is accepted.
On time delivery, in general 30 days. Multimode payment:T/T,L/C.
3.Special dimensions available according to request.
4.We have many certificates of our Products.
5.Accessories replacement if our product itself has quality problems during one year after receiving.
