Ball mill brief introduction:

Ball mill is the key equipment for the second crush of the materials. Ball mill is always used in the industy of producing cement,silicate wares,new pattern building materials, refractory material, fertilizer, ceramic… and can do dry and wet powder grinding for any kinds of ores.

Work Principle of Ball Mill:

The Ball Mill is a horizontal rotary drum apparatus driving by gears outside. It is a lattice pattern with two storage cells. The raw materials enter into the first cell of the Ball Mill evenly through the quill shaft in charging part. There are step liner palates or wave liner palates in the first cell which has been loaded various steel spheres of different scales. When rotating, the drum causes centrifugal force that brings the steel spheres to a certain height and then the spheres drop to impact and grind the materials. After the rough grinding in the first cell, the qualified partials will enter into the second cell through a single division plate .There are flat palates welded on the inner wall of the second cell, as well as steel spheres. The materials will be further grinded in it and at last the qualified granularities will be discharged through the unload part. Then the whole process is completed.

Structure Features:

Ball Mill consists charging part, discharging part, rotary part, transmission part (velocity decreasing machine, small conveying gear, motor, electric control) and so on. The quill shaft is made of casting steel and the inner liner palate is replaceable. The big rotary gear is processed by cast roll tooth. There is wear- resistant liner palates welded on the inner wall of the drum so that it has good wear proof ability. The Ball Mill operates stably and reliably.

It can be divided into dry Ball Mill and wet Ball Mill with lattice according to the materials and discharging way.

The Technical Parameter of Ball Mill:

Note: This specification is just reference, any changes are subject to the products.

Our Services

Pre-sale:
   (1) According to customer's special requirements, design and manufacture of products.
   (2) the company free of charge to the user onsite engineering and technical personnel planning site for the user to design the  best processes and programs.
Sale:
  (1) product acceptance.
  (2) to help customers develop construction programs.
After-sale:
  (1) free to assign a dedicated service personnel, arrived at the scene and guide customers installation.
  (2) equipment installation.
  (3)complete sets of equipment installed

Packaging & Shipping

Our products are usually packed by plywood case,wooden case,nylon coth, etc. And we will change packing ways by the real situation.

The goods will be delivred from Qingdao port and we will take buyers requirements into consider,too.
