Engineers available to service machinery overseas After-sales Service Provided and New Condition paper cup print machine
Specification :
This machien is a flexo printing machine which adopts flexible photosensitive resin plates, rubber plates as the base material,anilox rollers for transferring ink,liquid ink for printing . It is controlled centrally by PLC system aection and control section.
this machine is an ideal machine for printing paper cup, carton, paper bag, paper package.also can printing film (Except for PE material )
|
|
|
|
|
|
|
|
1.Unwinder Section
2.Printing Section
3.Rewinder Section
1. Other detail part
Main Technical Variables:
| Model | RZJ-1050A | RZJ-1350A | RZJ-1550A |
| Max.web width | 1050mm | 1350mm | 1550mm |
| Max. printing width | 1030mm | 1030mm | 1550mm |
| Max.die-cuttinG width | 1050mm | 1350mm | 1550mm |
| Printing repeat | 380-1200mm | 380-1600mm | 380-1600mm |
| Max.Unwinder diameter | 1524mm | 1524mm | 1524mm |
| Max. Rewinder diameter | 1524mm | 1524mm | 1524mm |
| Gearing | 1/8cp | 1/8cp | 1/8cp |
| Max. printing speed | 150m/min | 150m/min | 150m/min |
| Diameter of web roller | 100mm | 100mm | 100mm |
| Motor power | 11kw-15kw | 15kw-18.5kw | 18kw-22kw |
| Drying mode | A.Aqueos ink | B. UV ink | |
| Oil used | A.Warm Drying | B.IR Drying | C.UV Drying |
| Power requirementHZ | 380V 3PH 50 | 380V 3PH 50HZ | 380V 3PH 50HZ |
| Difference | Normal flex printing machine | High speed flex printing machine |
| Speed | 50-80m/min | 150m/min |
| Plate thickness | 2.38mm | 1.7mm |
| Video cam | Not suitable | Match |
| Register accuracy | Accuracy:+_0.50mm | Accuracy:+_0.12mm |
| Color | 1-6 color | 1-8.9.10 or more |
| Heating meothy | Fan Heating one time |
Independent external heating(safe) Hot air recycling (Energy saving ) |
| Loading device | Pneumatic | Hydraulic |
| Material of machine | The normal Iron | Double wal alloy cast iron |
| Bearing | Made in China | Made in Japan NSK |
Auxiliary Equipment For Printing Machine (Option)
1.Ultrasonic Cleaning Machine For Anilox Roller
2.FL Series of Flexo Plate Making Machine
3.ZX Series of Plate Mounting Machine
If want to see the video.PPT .Pls contact with Candy
To be the Best Printing&Packaging Manufacture in China
Company introduction:
- 14 years experience in packing industrial
- Appliance is strictly in accordance with CE standard
- Assembly&parts are processed by CNC lathe
- Good after-sale service
- Prompt reply within 24 hours
- Professional&enthusiastic sales team
FangBang Development History:
- August ,1999 ---Ruian.jianshe Packing Equipment Co.,Ltd ,Was established
- April ,2002 ---Shanghai Fangbang industry Co.,Ltd Wad established
- October, 2003 ---Main products passed the inspection of Zhejiang Province Light Industry Machine Quality Supervision and Inspection Center,past the Province Level Authentication an listed by Govenment Authorities as the new products
- August .2005 ---Jiangsu Fangbang Machinery Co.,Ltd Was established
- October .2005 ---Passed ISO9001:2000 Authentication
- May,2006 ---Zhejiang Fangbang Machiery Co.,Ltd .Was established
- Augus,2006 --- Passed CE Authentication
- July ,2010 --- The Famous Product of Ruian City
- September ,2010 -- The Famous Brand of Ruian City
- August,2011 --- National High&New Technology Enterprise
- ...........
Q1.Are you a manufactrer ?
Yes.we have been in provding professional printing and packaging industry over 14 years from 1999
Q2.Do you have stock products to sell
No.We work on OEM order ,That means ; size ,material ,quantity ,design packaging etc.depend on your requests
Q3.What information should I let you know if I want to get a quotation ?
- The size of the products
- The material
- The printing colors
- The quantity
If It is possible ,Please also provide with sample pictures which you need to make ,If not ,we will recommend you some products for reference
If you are interested in our machine .Pls feel free to contact with me :
Zhejiang Fangbang Machinery Co.,Ltd
Add : Qianbu Industrial Area.Xincheng Street .Ruian City .Zhejiang
M.T:+86-18867730098 +86-13587501104
Direct Line: +86-577-65186883
Skype: zhezhoutiankong Wechat : candy663555 Facebook: candy chi
Website:
