BG2-80 2 Color Automatic Penholder Screen Printer With CE,ISO

BG2-80 2 Color Automatic Penholder Screen Printer With CE,ISO thumbnail-1
BG2-80 2 Color Automatic Penholder Screen Printer With CE,ISO photo-1
US$ 85,000 - 110,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Screen Printer
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Luen Cheong Printing Equipment Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN CHINA
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Screen Printer
Place of Origin Guangdong, China
Brand Name LC
Model Number BG2-80
Usage Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer, Tube Printer
Automatic Grade Other, Automatic, Automatic
Voltage 220V
Gross Power 6.3kw, 6.3KW
Dimensions(L*W*H) 3200*1120*1520mm
Weight 630kg
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.It can print conicity products,and the maximum conicity is 3 degrees
2.Printing speed:2 color--3600pcs/hr 1 color--7200pcs/h


Product Description



Product name

 BG2-80 2 color Automatic Penholder Screen Printer with CE,ISO

Model No

 BG2-80

Certificate

CE, ISO-9001-2000

Brand Name

 LC,CHINA

Description

1. One operator, the two orbits can work at the same time. The machine can be stopped to clean screen frame, adding ink at any time, and the machine designed specially to make sure the pen-holder won’t be scorch and out of shape when the machine stop working.

The printing objects won’t be scorch and out of shape when the machine stop.

2. It can print conicity products, and the maximum conicity is 3°.

3.The printing baseplate has the vacuum function(optional) which can ensure the precision of registering.

5. The machine can printing two differents patterns or different kinds of pen-holders at the same time.

6. It have dust-abatement device (optional), which can clean dust on pen-holder before printing.

7. Double scrapers design to keep printing and ink flooding perfectly and reliable.

Advantage

1. Full electric control, no need compress air, and automatic register control.

2. Uploading and downloading pen-holder automatically, The machine can printing in 1 or 2 orbits, and printing patterns in 1 or 2 colors.

3.The machine run smoothly, and the printing speed and printing stroke are adjustable.

4.Taiwan made transducer which ensure the printing effect consistently.

5.Adopt IR infrared ray (or UV ultraviolet radiation drying system, optional), printing and drying can be finished at the same time.

6.Application: The machine be widely used in the printing of ball pen, water erasable pen, pencil, marker pen, eyebrow pencil, lipstick, medical test tube, etc.

Parameter

1.Diameter of printing objects:   1 color : φ3~φ20mm     2 color: φ8~φ20mm

2.Length of printing objects: 60~160mm

3.Width of printing route: 20~80mm

4.Printing speed:  1 color: 7200pcs/hr    2 color: 3600pcs/hour

5.Power: 220V  50/60Hz  6.3KW

6.Weight :630kg

7.Machine Dimension: 3200×1120×1520mm

Free fittings

 1Set/Sets

Shipping way

 By sea, by air, by express

Delivery time

 Within 7 days from the receipt of payment

Loading seaport

 Shenzhen or Hong Kong, China

package

 WOODEN CASE

Price term

 FOB Shenzhen, CFR, CIF, FCA, EXW etc

Payment term

 100% T/T in advance(negotiation)
