(LCB-120UV-1)Full Automatic One Colour Cylinder Screen Printer

(LCB-120UV-1)Full Automatic One Colour Cylinder Screen Printer thumbnail-1
(LCB-120UV-1)Full Automatic One Colour Cylinder Screen Printer photo-1
US$ 15,000 - 22,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Screen Printer
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Luen Cheong Printing Equipment Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN CHINA
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Screen Printer
Place of Origin Guangdong, China
Brand Name LC
Model Number LCB-120UV-1
Usage Tube Printer
Automatic Grade Automatic
Voltage 380V
Gross Power 5.5kw
Dimensions(L*W*H) 2.0*1.1*1.55m
Weight 1500KGS
Certification CE

Specifications

1.screen printer with high printing precision
2.auto bottle /cylinder printing
3.with uv dryer system
4.with high speed

 Full  Automatic One Colour Cylinder Screen Printer LCB-120UV-1.
This auto printing press system is specially used for printing different patterns on the objects with round shape or oval shape. As it is made up of several individual units to form a printing chain, it can be used for the purpose of one-color printing. The materials to be printed can be plastic, glass, ceramics, metal, etc



1. MAIN MOTOR: SITI(Italy)
2. PLC: Omron(Japan)
3. SENSOR: Optex(Japan)
4...TOUCH SCREEN: Proface(Japan)
5. Switch: Schneider(France)
6. (CONTACTOR): (Schneider)(France)
7(RELAY): (Idec)(Japan)
8. (INVERTER): Omron(Japan)
9. (UV CURING)(Primarc brand uv lamp ) Britain
10. (PNEUMATIC): Festo(Germany)


1 Model No:LCB-120UV-1
2.Printing colors:1 color
3.Product appearance:Round bottle /  oblate bottle
4.Operation:Full Auto
5.min printing diameter:round bottle: 20 mm
6.max printing diameter:round bottle :100 mm
7.min printing radius:oblate bottle :25 mm
8.max printing radius:oblate bottle :260 mm
9.oblate bottle width:20-100 mm
10.oblate bottle thickness:20-80 mm
11.Max Printing speed:4000-5000Pcs/Hr
12.Power:380V
13.Weight:1050(kg)
14.Dimensions:L:1900×W:1000×H:1500(mm)

1-COLOUR AUTO SCREEN PRINTER
Model No LCB-120UV-1 LCB-150UV-1 LCB-350UV-1
Printing colors 1 color 1 color 1 color
Product appearance Round bottle  oblate bottle Round bottle  oblate bottle Round  bottle
Operation Full Auto Full Auto Full Auto
min printing diameter(round bottle) 20 mm 20 mm 150 mm
Max printing diameter(round bottle) 100 mm 150 mm 350 mm
min printing radius (oblate bottle) 25mm 25mm /
max printing radius (oblate bottle) 260mm 300mm /
oblate bottle width 20-80 mm 20-100 mm /
Max Printing speed 4000-5000Pcs/Hr 4000-5000Pcs/Hr 2000Pcs/Hr
Power 380V 380V 380V
Weight 1050kg 1360kg 1550kg



  1.Full automatically printing suitable to print on various shades of cylindrical, elliptical and falt workpieces;

 2.Coupled with auto workpiece feeding and loading system;

3.Flame treatment device adopted for re-treatment on PE or PP workpieces to get ultimate ink adhesion;
4.The function of workpiece placing in advance is built-in aiming on cylindrical or elliptical printing;
5.Electric sensor creates "no workpiece no printing" that leads to intelllgent monitor and smart control;
6.High quality UV curing system adopted to ensure fast ink drying and color registration;
7.High printing speed that up to 4000pcs/hr will bring you with high productivity;
8.Conveniently and easily fixture adjustment and change that save your valuable time;
9.Multi-sets of this machine can achieve 2-color, 3-color and even 4-color auto printing system..
