Control Flexible Cable to BS6500
Application:
Used as interconnecting cable for measuring, controlling or regulation in control equipment for assembly and production lines, conveyors and for computer units. Suitable for fixed installations or for flexible use in conditions of light mechanical stress. Can be used outdoors when protected, and in dry or moist conditions indoors.
Standards: Generally to BS6500, VDE0250
Construction
Conductor: Class 5 flexible plain copper conductors
Insulation: PVC (Polyvinyl Chloride)
Sheath: PVC (Polyvinyl Chloride)
Sheath Colour: Grey,Black,or By Order
Voltage Rating: 300/500V
Temperature Rating:
Fixed: -35° C to + 70° C
Flexing: -5° C to + 70° C
Minimum Bending Radius: 10 x overall diameter
Core Identification:
Black with White numbers. (3 cores and above to include Green/Yellow). Coloured cores available.
Type and Data | |
Control Flexible Cable to BS6500 | |
No. of Cores x Nominal Cross Sectional Area # x mm² |
Nominal Overall Diameter mm |
2 x 0.50 |
5.20 |
2 x 0.75 |
5.70 |
2 x 1.00 |
5.90 |
2 x 1.50 |
7.10 |
2 x 2.50 |
8.30 |
3 x 0.50 |
5.50 |
3 x 0.75 |
6.04 |
3 x 1.00 |
6.26 |
3 x 1.50 |
7.54 |
3 x 2.50 |
9.04 |
3 x 4.00 |
10.90 |
3 x 6.00 |
12.40 |
3 x 10.00 |
15.50 |
3 x 16.00 |
18.40 |
4 x 0.50 |
5.98 |
4 x 0.75 |
6.58 |
4 x 1.00 |
7.02 |
4 x 1.50 |
8.23 |
4 x 2.50 |
9.87 |
4 x 4.00 |
11.90 |
4 x 6.00 |
13.60 |
4 x 10.00 |
17.20 |
4 x 16.00 |
20.20 |
5 x 0.50 |
6.53 |
5 x 0.75 |
7.41 |
5 x 1.00 |
7.68 |
5 x 1.50 |
9.23 |
5 x 2.50 |
11.05 |
5 x 4.00 |
13.10 |
5 x 6.00 |
15.10 |
5 x 10.00 |
18.90 |
5 x 16.00 |
22.20 |
5 x 25.00 |
29.00 |
7 x 0.50 |
7.30 |
7 x 0.75 |
8.05 |
7 x 1.00 |
8.55 |
7 x 1.50 |
10.05 |
7 x 2.50 |
12.25 |
12 x 0.50 |
9.70 |
12 x 0.75 |
10.94 |
12 x 1.00 |
11.36 |
12 x 1.50 |
13.64 |
12 x 2.50 |
16.54 |
18 x 0.50 |
11.50 |
18 x 0.75 |
12.95 |
18 x 1.00 |
13.65 |
18 x 1.50 |
16.35 |
18 x 2.50 |
19.75 |
25 x 0.50 |
13.80 |
25 x 0.75 |
15.50 |
25 x 1.00 |
16.10 |
25 x 1.50 |
19.50 |
25 x 2.50 |
23.50 |
YITENG COMPANY
Yiteng Cable Technology Hebei Co., Ltd
Established Year: 2014
Registered capital of RMB:100,000,000
Factory Area:36,000m2
Manufacturing Capacity per year: 250000km
Number of Employees: 250
Main products:
Bare conductors(AAC,ACSR,AAAC,ACAR,Aluminum Clad Steel Conductor);
Aerial Bundled Cable (ABC Cable);
Power cable,Electrical wire cable,
Armored cables,
Control cables,
Rubber insulated cables, PVC insulated wires and cables,
Battery cables,Instrument cables, Coaxial cables,Flat cables,
Welding cables,House wire,Special Cables etc.
FAQ:
1.Q: Is your company a manufacturer or a trade company?
A: We are cable manufacturer.
2. Q: Where is your factory located? How can I visit there?
A:Our factory is located in Ningjin City, HebeiProvince, China. You can fly to Shijiazhuang airport directly. All our clients, from home or abroad, are warmly welcome to visit us
3. Q: What is your sample policy?
A: Some of our samples are available for free, while others are available at a cost, which will be deducted from the purchase order.
4.Q: How does your factory do regarding quality control?
A: Quality is priority. We always attach great importance to quality controlling from the very beginning to the very end.
5. Q: I am very interested in your product, can you sent me your full catalog and pricing list?
A: We can select some popular products for you immediately. Please let us know your requirements so that we can send out the quotation to you.
