High Quality, PVC Insulated or XLPE Insulated Multicore Screened Control Cable
Standard : The products can be produced according to the standard GB9330-2008, and the factory can also manufacture the cable with other standards.
Scope of appliance :The products are suitable for the connection of controlling electrical equipments and instruments meters, monitoring and controlling return circuit, protecting and measuring in power distribution unit under the circumstance that the rated voltage is up to 450/750V AC.
The requirement for using
1). The longterm working temperature of conductor of PVC insulated cable is 70 degrees, the longterm working temperature of conductor of XLPE insulated cable is 90 degrees.
2). The temperature for laying the cables cannot be less than 0 degrees,
3). Permissible curved radius(r): Unarmoured cable: R≥ 6D, Armoured or copper tape screened cable: R≥ 12D Shielded flexible cable: R≥ 6D. (D: Outer diameter of the cable)
Model and Data
Type |
Designation |
KVV |
Copper conductor,PVC insulated,PVC sheathed control cable |
KVVP |
Copper conductor,PVC insulated,PVC sheathed,Braided shield control cable |
KVVP2 |
Copper conductor,PVC insulated,PVC sheathed,copper tape shield control cable |
KVV22 |
Copper conductor,PVC insulated, PVC sheathed,steel tape armored control cable |
KVV32 |
Copper conductor,PVC insulated, PVC sheathed,steel wire armored control cable |
KVVR |
Copper conductor,PVC insulated,PVC sheathed flexible control cable |
KVVRP |
Copper conductor,PVC insulated,PVC sheathed,Braided shield flexible control cable |
KVVP-22 |
Copper conductor,PVC insulated,PVC sheathed,Braided shield, steel tape armored control cable |
YITENG COMPANY
Yiteng Cable Technology Hebei Co., Ltd
Established Year: 2014
Registered capital of RMB:100,000,000
Factory Area:36,000m2
Manufacturing Capacity per year: 250000km
Number of Employees: 250
Main products:
Bare conductors(AAC,ACSR,AAAC,ACAR,Aluminum Clad Steel Conductor);
Aerial Bundled Cable (ABC Cable);
Power cable,Electrical wire cable,
Armored cables,
Control cables,
Rubber insulated cables, PVC insulated wires and cables,
Battery cables,Instrument cables, Coaxial cables,Flat cables,
Welding cables,House wire,Special Cables etc.
FAQ:
1.Q: Is your company a manufacturer or a trade company?
A: We are cable manufacturer.
2. Q: Where is your factory located? How can I visit there?
A:Our factory is located in Ningjin City, HebeiProvince, China. You can fly to Shijiazhuang airport directly. All our clients, from home or abroad, are warmly welcome to visit us
3. Q: What is your sample policy?
A: Some of our samples are available for free, while others are available at a cost, which will be deducted from the purchase order.
4.Q: How does your factory do regarding quality control?
A: Quality is priority. We always attach great importance to quality controlling from the very beginning to the very end.
5. Q: I am very interested in your product, can you sent me your full catalog and pricing list?
A: We can select some popular products for you immediately. Please let us know your requirements so that we can send out the quotation to you.
