450/750V Multicore Copper Conductor PVC Insulated and Sheathed Braiding Screened/Shielded Control Cable

450/750V Multicore Copper Conductor PVC Insulated and Sheathed Braiding Screened/Shielded Control Cable

Product Description

450/750V 37*1.5mm2 Multicore copper conductor PVC Insulated and Sheathed Braiding Screened/Shielded Control Cable

Standard : The products can be produced according to the standard GB9330-2008, and the factory can also manufacture the cable with other standards.

Scope of appliance :The products are suitable for the connection of controlling electrical equipments and instruments meters, monitoring and controlling return circuit, protecting and measuring in power distribution unit under the circumstance that the rated voltage is up to 450/750V AC.

The requirement for using

1). The longterm working temperature of conductor of PVC insulated cable is 70 degrees, the longterm working temperature of conductor of XLPE insulated cable is 90 degrees.

2). The temperature for laying the cables cannot be less than 0 degrees,

3). Permissible curved radius(r): Unarmoured cable: R≥ 6D, Armoured or copper tape screened cable: R≥ 12D Shielded flexible cable: R≥ 6D. (D: Outer diameter of the cable)

Model and Data

YITENG COMPANY

Yiteng Cable Technology Hebei Co., Ltd
Established Year: 2014
Registered capital of RMB:100,000,000
Factory Area:36,000m2
Manufacturing Capacity per year: 250000km
Number of Employees: 250

Main products:
Bare conductors(AAC,ACSR,AAAC,ACAR,Aluminum Clad Steel Conductor);

Aerial Bundled Cable (ABC Cable);

Power cable,Electrical wire cable,

Armored cables,

Control cables,

Rubber insulated cables, PVC insulated wires and cables,

Battery cables,Instrument cables, Coaxial cables,Flat cables,

Welding cables,House wire,Special Cables etc.
