Bluetooth Serial Server for wireless connection-BSP1000

Specifications

The BSP1000 is an Industrial Bluetooth SPP server designed to connect Bluetooth devices to the 10/100 Base-T Ethernet network

 Bluetooth Serial Server for wireless connection-BSP1000





The BSP1000 is an Industrial Bluetooth SPP server designed to connect Bluetooth devices to the 10/100 Base-T Ethernet network with advanced features. These Bluetooth Access Points transmit data from each Bluetooth terminal to management station via TCP/IP.



Available in 7, 14, and 28 Bluetooth connection models, the BSP1000 Bluetooth SPP Server product line incorporates Bluetooth 2.0 Protocol Stack with Enhanced Data Rate (EDR) support; and transmits data from each Bluetooth terminal to management station via TCP/IP.







Key Features:

Linux built-in

Connect Bluetooth Devices to 10/100M Ethernet

Supports up to 3Mbps data rate

Ideal Wireless solution for the replacement of the wired multi-port serial card

7/14/21/28 Bluetooth connections support

Supports Bluetooth profiles for Serial Port,

COM port redirector support

Flexible TCP/UDP host mode support: multiple host connction/data transfer

Support RFC 2217, Telnet COM port control protocol





Applications:

Truck/Bus monitoring system

Car Diagnostic

Wireless POS system

Wireless Factory monitor PLC programming

Wireless machine(healthcare/industrial) Monitoring

Wireless Printing

Wireless Logistic



Specifications:





Model No.		BSP1000A	BSP1000B	BSP1000C	BSP1000D
Bluetooth	SPP connections	7	14	21	28
	Bluetooth	Blueooth 2.0+EDR
	Bluetooth stack	RFCOMM / L2CAP
	Data Rate	Up to 3Mbps
	Bluetooth standard	Class 1
	Working Range	Up to 300 meters in open space
	Max. RF output	19.5dBi
	Receiving Sensitivity	-92.5dBi
	Antenna Gain	7dBi
Network	Interface	One RJ45
	Protection	2KV Isolation
	Data rate	10M/100M adapter
	Protocols	ICMP/ARP/TCP/HTTP/SSH/DNS/DHCP/DNS/DDNS
Operation	Working Mode	Virtual COM port/TCP Server/TCP Client/UDP Sever/UDP Client
	System	Windows 98/ME/NT/2000/XP/2003/WIN7
	managment	VSPP service and configure software
	Firmware upgrade	Via LAN/USB DISK/NET
AC/DC	Input Voltage	12~15VDC
	Power	230mA/12V
Environmental	Operating	-20~80°C
	Storage	-30 ~85°C
	Humidity	5 - 95%RH
Physical	Dimension	17.3x12.8x2.8CM (LxWxH)
	Material	ABS plastic
Approval	CE	CE
		FCC
