RS232/485 2 port Bluetooth and WiFi AP serial instrument
Product Description
The BSP1000 is an industrial wireless Bluetooth AP designed to collect data from each Bluetooth terminal and transmit these data to management station (Server/computer ) via the 10/100 Base-T Ethernet network or WiFi, so you can monitor real-time data of each Bluetooth terminal and manage these devices remotely.
How it works
Truck/Bus monitoring system |
| Car Diagnostic |
| Wireless POS system |
| Wireless Factory monitor PLC programming |
| Wireless machine(healthcare/industrial) Monitoring |
| Wireless Printing |
| Wireless Logistic |
Application
Specifications
System Hardware Information
Processor |
Embedded MIPS24KEc |
Working frequency |
580Mhz |
Memory |
128MBytes DDR2 |
Flash |
32MBytes |
Network |
1 10M/100M |
WIFI |
802.11n 2.4 GHz 150M |
Emission power |
16.5DB |
RS232/RS485 |
2 Channel |
Bluetooth Connect |
7 Channel (Optional) |
Power Input |
DC 9~28V |
Power consumption |
1A/12V |
Working temperature |
-20~80℃ |
Storage temperature |
-30 ~85℃ |
Operating humidity |
5 - 95%RH |
Package Size |
|
Certification |
FCC/CE |
Network parameters
Speed |
10/100M Auto |
Electromagnetic isolation |
2KV |
Network Protocol |
IP/TCP/UDP/DHCP/DHCPD/DNS/HTTP/SNMP |
MAX TCP Connectors |
4096 |
SDK Soft |
PHP5.5 |
Setting Mode |
Software / Webserver |
WiFi parameters
Frequency |
2.4G |
Interface |
SMA RF Antenna |
Transmission power |
+16.5 DB (802.11n) |
Sensitivity |
-75DB (802.11n) |
Encryption |
WPA/WPA2 TKIP/AES |
Transmission Distance |
400M |
Work Mode |
Station/AP |
User Number |
MAX 120 |
UART RS232 Information
RS232 Port |
1 |
Baud rate |
300~230400BPS |
Data bit |
5/6/7/8 Bits |
Stop Bit |
1/2 Bits |
Check |
None/Odd/Event |
Buffer Size |
4MBytes |
Interface |
DB9 Female Head and Male Pin |
UART RS485 Information
RS485 Port |
1 |
Baud rate |
300~230400BPS |
Data bit |
5/6/7/8 Bits |
Stop Bit |
1/2 Bits |
Check |
None/Odd/Event |
Buffer Size |
4MBytes |
Interface |
Two Line (A,B) |
Bluetooth (Optional)
Frequency |
2.4G |
SPP Channel |
7 |
Speed |
MAX 3MBps |
Interface |
SMA RF Antenna |
Emission power |
6.5DB |
Sensitivity |
-103DB |
Support Bluetooth version |
4.0/3.0/2.1/2.0 |
How to manage the Bluetooth AP?
We have provided free softwore to manage the Bluetooth AP, it's easy to set the work mode ,you can easily control it remotely.
