Specifications
Same like SD16 with weichai power 140HP diesel engine,popular for exporting to Africa and Russia markets.SHANTUI/TIANGONGTY165-2 Bulldozer:
TY165-2 bulldozer is 165 horsepower track-type dozer with hydraulic direct drive, semi-rigid suspended and hydraulic assisting operating, pilot hydraulic blade control and single level steering and braking control.
TY165-2 bulldozer is characterized by high efficient, open view, optimized structure, easy operation and service with low cost and reliable entire quality. It can be equipped with three shanks ripper, U-blade (7.4 cubic meter capacity) and other optional components.
TY165-2 bulldozer is applicable for earth handling in road construction, desert and oil-field working, farmland and port construction, irrigation and electric power engineering, mining and other engineer conditions. It is the upgrade product of TY165-1 bulldozer.
TY165-2 Bulldozer Specifications:
| NO. | item | Parameter |
| 1 | Dozer | Tilt |
| 2 | Operation weight not include repper |
17800kg |
| 3 | Ground pressure | 69kPa |
| 4 | Track gauge | 1880mm |
| 5 | Gradient | 30/25 |
| 6 | Min. ground clearance | 352.5mm |
| 7 | Dozing capacity | 5.0m3 |
| 8 | Blade width | 3297mm |
| 9 | Max Digging depth | 420mm |
| 10 | Overall dimensions | 5416*3297*3160mm |
TY165-2 Bulldozer engine:
| NO. | item | Parameter |
| 1 | Type | Weichai WD10G178E15 |
| 2 | Rated revolution | 1850rpm |
| 3 | Flywheel power | 121/165kw/hp |
| 4 | Max. torque | 830/1100N.M/RPM |
| 5 | Rated fuel consumption | less 218g/kw.h |
TY165-2 Bulldozer undercarriage system:
| NO. | item | Parameter |
| 1 | Type | Swing type of sprayed beam Suspended structure of equalizer bar |
| 2 | Number of track rollers (each side) | 6 |
| 3 | Number of carrier rollers (each side) | 2 |
| 4 | Pitch | 203mm |
| 5 | Width of shoe | 500mm |
TY165-2 Bulldozer Gear:
| NO. | item | Parameter |
| 1 | Forward | 0-3.32 km/h (1st) 0-6.62 km/h (2st) 0-11.40 km/h (3st) |
| 2 | Backward | 0-4.00 km/h (1st) 0-7.57 km/h (2st) 0-13.87 km/h (3st) |
TY165-2 Bulldozer implement hydraulic system:
| NO. | item | Parameter |
| 1 | Max systme pressure | 12mpa |
| 2 | Pump type | Two groups gears pump |
| 3 | System output | 190L/min |
TY165-2 Bulldozer Driving system:
| NO. | item | Parameter |
| 1 | Torqure converter | 3-element 1-stage 1-phase |
| 2 | Transmission | Planetary,power shift transmission with three speeds forward and three speeds reverse, speed and direction can be quickly shifted |
| 3 | Steering clutch | Multiple-disc oil power metallurgy disc compressed by spring, hydraulic operated |
| 4 | Braking clutch | Brake is oil two direction floating band brake operated by mechanical foot pedal |
| 5 | Final drive | The final drive are double reduction with spur gear and segment sprocket,which are sealed by duo-cone seal. |
Bulldozer:
- T140-1 Bulldozer
- SD6G Bulldozer
- SD7 Bulldozer
- SD7CL Bulldozer
- SD8B Bulldozer
- SD9 Bulldozer
- Ty165-2 Bulldozer
- T165-2 Bulldozer
China bulldozer Brands: SHANTUI bulldozer, XUANGONG bulldozer, HBXG bulldozer, and so on. chinese bulldozer has many advantage, chinese bulldozer price is lower and quality is high.
China bulldozer Brands: SHANTUI bulldozer, XUANGONG bulldozer, HBXG bulldozer, and so on. chinese bulldozer has many advantage, chinese bulldozer price is lower and quality is high.
