Help CenterSD52 Bulldozer Popular for Russia and Brazil Markets ZOT Brand
Related Products
-
SD16 Bulldozer Popular for Russia and Brazil Markets ZOT BrandNegotiableMOQ: 1 Unit -
SD22 Bulldozer Popular for Russia and Brazil Markets ZOT BrandNegotiableMOQ: 1 Unit
-
SD10YE Bulldozer Popular for Russia and Brazil Markets ZOT BrandNegotiableMOQ: 1 Unit
-
SD32 Bulldozer Popular for Russia and Brazil Markets ZOT BrandNegotiableMOQ: 1 Unit
-
SD23 Bulldozer Popular for Russia and Brazil Markets ZOT BrandNegotiableMOQ: 1 Unit
Specifications
small bulldozer,cummins engine,ytr engine,pupular for exporting with CE and gost,high quality,shantui made in ZOT brand. The extended track ensures low ground pressure, high reliability and strong traction, contributing to precise operation;
The power shift transmission not only ensures smooth power shift, but also reaches target speeds and carries out directional transfers with a single control lever;
The wet steering clutch and brake can extend service life. They work interactively, ensuring quick and flexible steering operations;
The single control lever can control all blade actions;
The drift sealing in the drive wheel, track roller and carrier roller can prevent dust from entering the track system, as well as lubricant leakage, thereby ensuring a long service life;
The hexahedron cab features wide visibility, and the insulation materials in the cab can reduce noise and vibrations;
The spin type fuel filter and dust separator, the air filters and the other filtration devices can prolong work time and reduce service time;
The comfortable cab seat can adjust upward and downward, forward and backward, meeting any positional needs the operator may have;
Side engine operation and the combination of a drive/brake operation system and foot brake makes overall operation of the bulldozer more rapid and convenient.
| ITEM | UNIT | SD52-5 |
|---|---|---|
| L×W×H(Ripper not included) | mm | 10420×4680×4470 (Ripper included) |
| Operating weight(Ripper not included) | t | 67.5(Ripper included) |
| Engine | - | Cummins QSK19 |
| Engine Emission standard | - | Euro III |
| Rated power | kW/rpm | 392/1800 |
| Gradeability | ° | 30 |
| Blade type | - | Semi-U blade |
| Blade width | mm | 4695×2265 |
| Dozing capacity | m3 | 18.5 |
| Ma× drop below ground of blade | mm | 720 |
| Lift height of blade | mm | 1660 |
| Ripper type | - | Single ripper |
| Ripping depthof ripper | mm | 1435 |
| Lifting height of ripper | mm | 1105 |
| Number of carriers (each side) | - | 2 |
| Number of track rollers (each side) | - | 7 |
| Number of track shoes (each side) | - | 40 |
| Width of track shoe | mm | 610 |
| Track gauge | mm | 2500 |
| Ground length and ground pressure | mm/MPa | 3940-0.138 |
| Pitch | mm | 280 |
| Forward speed | km/h | 0–3.8 |
| 0–6.8 | ||
| 0–11.8 | ||
| Reverse speed | km/h | 0–5.1 |
| 0–9.2 | ||
| 0–15.8 |
