UV-5200 Lab UV/VIS Spectrophotometer
Technical parameters of UV-5200 Lab UV/VIS Spectrophotometer:
1. Model: UV-5200
2.Optical System: Single beam, Grating 1200 lines/mm
3.Wavelength Range: 190-1000nm
4.Bandwidth: 2nm
5.Wavelength Accuracy: ±1nm
6.Wavelength Repeatability: 0.5nm
7.Wavelength Setting: Auto
8.Photometric Accuracy: ±0.3%T
9.Photometric Repeatability: 0.2%T
10.Photometric Range: -0.3-3A,0-200%T, 0-9999C
11.Stray Light: ≤0.1%T
12.Stability: ± 0.002A/h @ 500nm
13.Display: 128*64 Dots LCD
14.Detector: Silicon Photodiode
15. Printer Port: Parallel Port
16.Output: USB Port
17.Lamps: D2 Lamp & W Lamp
18. Power Requirements: AC 220V/50Hz or 110V/60Hz
19.Dimension: 460*360*225mm
20.Weight: 18kg
Main feature of UV-5200 Lab UV/VIS Spectrophotometer:
1.Large LCD screen(128x64Dots).Can display total 200 groups of data,5 groups per screen. Can display standard curve and the curve equation.
2.Can save 200 groups of curve equation. Convenient for check and reload.
3.Data can be restored after a sudden power cut.
4.Auto setting wavelength. Auto zero and blank.
5.Tungsten lamp & deuterium lamp can be turned on/off individually to extend lifetime.
6.The Toption application software UV-Professional provides complete control of the spectrophotometer from a computer through the Built-in USB port. The following functions can be easily achieved: Quantitative, Kinetics, Wavelength Scan, DNA/Protein Test and Multi-wavelength Test.
7.The flange of the D2 lamp makes it become true Pre-aligned design makes it convenient to change lamps.
8.Large sample compartment, It can accommodate 5-100mm path length cuvettes with optional holders. A variety of optional accessories are under your choice.
